Chapter 1: Overview
Using this Manual
Page 3
Model Identification
Each unit is identified by a model number, such as M-OD.13E1C3DR410.230/1/60.DC. The elements in the number
are explained in
Table 2.
Table 2: Model Number Nomenclature
M-OD.13E1C3DR410.230/1/60.AC
Product series name: M-OD = MOBILECOOL-OUTDOOR：Packaged air conditioner with fresh air free cooling.
Unit nominal total cooling capacity in kW
Compressor type & number: E1 = Hermetic scroll compressor qty 1; R1= Rotary compressor qty 1
Cabinet size code: There are 4 cabinet sizes: C1, C2, C3 & C4.
Control configuration: D = Unit is designed to operate in a Dual control environment (aka Lead/Lag operation)
Refrigerant: R410 = R410a.
Power source: Voltage/Phase/Frequency; 230V/1φ/60Hz, 230V/3φ/60Hz, 460V/3φ/60Hz.
Supply Fan configuration: DC = DC EC fan; AC = AC EC fan. (EC = Electronically commutated variable speed fan)
Special code: Utilized to designate unit customization (non-standard configuration)
