Chapter 2: Installation
Controller Box Installation
Page 25
The supply air temperature sensors should be installed at the middle-front of the supply air grill as shown in Figure
19.
Figure 19: Position Supply Air Temperature Sensors
Two screws should be
used for fixing the supply
air temperature sensor
mounting hardware.
Supply air temperature
sensor location
