Service Manual Aktilite

CL128

Version 1.

Page 13

of 41

Step 3

Step 2

5 is only necessary if you need to take off the

main arm, the housing or replace the cable.

Remove the strain relief.

Not applicable for lamps with detachable lamp

head

Step 4

Step 2

5 is only necessary if you need

to take off the

main arm, the housing or replace the cable.

Remove the small cover on the main arm

using the

T10 screwdriver

Step 5

Step 2

5 is only necessary if you need to take off the

main arm, the housing or replace the cable.

Feed a few cm

of cord through the arm to make a

loop as shown.
