Service Manual Aktilite
CL128
Version 1.
3
Page
8
of
41
1.6.2
D
et
a
chable lamp head
Required Items
Part #
# of items
Description
128
-0-
437
1 T-
piece (Moulded plastic)
128
-1-
910
2
Plastic bearing
128
-0-
428
1
Main arm (Moulded plasti
c)
128
-1-
914
2
Aluminium washer
128
-1-
912
1
Conical spring
128
-1-
916
1
Circlip
128
-0-
988
1
Cable from system electronics to lamp head connector
128
-1-
926
2
Screw
PT3x25
Assembly description
Step 1)
Press the two plastic bearing
s (128
-1-
910) into the T
-
piece (128
-0-
437). (Specially made tool
is necessary for this or a jig made by Kitron.)
Step 2)
Broach the plastic bearings to Ø16,2mm after insertion in T
-
piece
Step 3)
Slide conical spring (128
-1-
912) onto aft tube of the main arm (128
-0-
428), T
he pointed end of
the conic spring (128
-1-
912) goes towards the plastic of the main arm (128
-0-
428).
Step 4)
Assemble one aluminium washer (128
-1-
914) and the T
-
piece (128
-0-
437) (Including the
already assembled plastic bearings (128
-1-
910)).
Step 5)
Compress the conical
spring (128
-1-
912) by holding the T
-
piece (128
-0-
437) tightly against
the main arm (128
-1-
428). (This compression and holding can be done with one hand.)
Step 6)
Assemble another aluminium washer (128
-1-
914) and circlip (128
-1-
916). Make sure that the
Circlip is
well located in the groove.
Step 7)
Assemble power cable assembly (128
-0-
988) by inserting the cable thru the positioning arm
module (128
-0-
400).
Step 8)
Put in the cord and fasten the T
-
piece cover (128
-1-
424) in the power cable assembly (128
-0-
988) using the two PT3x25
screws (128
-1-
926).
