Service Manual Aktilite
CL128
Version 1.
3
Page 36
of 41
3.2
PS electronics module (128
-0-
330) assembly
Required items
Part #
#
of items
Description
128
-1-
331
1
PS electronics
Tested to medical std. and adjusted by Kitron
128
-0-
332
1
Cable A
Blue AC conductor
128
-0-
333
1
Cable B
Brown AC conductor
128
-0-
334
1
Cable C
Green/yellow
ground
cable
128
-0-
335
1
Cable D
Red D
C cable
128
-0-
336
1
Cable E
Black DC cable
128
-1-
337
1
Ferrite (for the load cables)
Tool A
-
Screwdriver, pozidrive 2
Assembly description
Step 1)
Assemble the cables A (128
-0-
332), B (128
-0-
333) and C (128
-0-
334) to the power supply
electronics (128
-1-3
31), by using Tool A. Cable A (blue) is connected to the terminal
marked N, Cable B (brown) is connected to the terminal marked L, and Cable C
(green/yellow) is connected to the terminal marked with the ground symbol. Bend the three
cable shoes to a 45 deg
ree angle upwards when the electronics lies flat on the table.
Step 2)
Assemble the cables D (128
-0-
335) and E (128
-0-
336) to the power supply electronics, by
using Tool A. Cable D is connected to terminal 1, and cable E is connected to terminal 4.
Step 3)
Thread both loa
d cables (Cables D and E) through the ferrite (128
-1-
337) 5 times.
Step 4)
Make sure that the 7 cable terminal screws are securely tightened.
Step 5)
Remove the two printed forms that are tucked between some components on the power
supply electronics. Save them for markin
g of the complete unit and the Device History
Record.
