Service Manual Aktilite
CL128
Version 1.
3
Page
3
of
41
This service manual is primarily meant for mechanical repairs
and covers both Aktilite
CL128 lamps
with fixed and deta
chable lamp head
.
The electronic control board in the lamp head has to be programmed with the parameters
to match
the
calibrated light module. If the electronic control board is faulty then the complete board is changed and
programmed with the original p
arameters for the light module
.
These
can
only
be
r
etrieved from the
Device History Record for the lamp kept at the factory
and entering the device factory programming
mode can only be done by trained service personnel. The
light module consist of led arra
ys, heat sink
and lenses.
If a led diode is faulty then the complete
light module
is changed.
If a power supply
electronics board
is faulty, a new tested power supply can be obtained from
Photocure.
However, this has to be tested for leakage current,
eart
h continuity and withstanding voltage
test by qualified personnel.
1
Assembly of Aktilite CL128 Lamp with Parallel Arm
1.1
Material/Equipment
1.1.1
Tools needed for the assembly of lamp
with fixed lamp head
Required tools
# of
items
Description
1
Screwdriver,
Pozidrive 1
1
Screwdriver, Pozidrive 2
1
Screwdriver, Torx
T 7
1
Screwdriver, Torx
T 10
1
Screwdriver, Torx T 20
1.1.2
Tools needed for the assembly of lamp with detachable lamp head
Required tools
# of
items
Description
1
Screwdriver, Pozidrive 1
1
Screwdriver, Pozidrive 2
1
Screwdriver, Torx T 10
1
Screwdriver, Torx T 15
1
Screwdriver, Torx T 20
1
Allen key, 5mm
Umbraco
1
Press nut tool
1
Crimping tool LEMO DPC.91
-
701V
1
Locator male DCE.91.135.BVC
1
Locator female DCE.91.130.BVM
1
Ex
traction tool LEMO DCF.91.133.5LT
