Service Manual Aktilite
CL128
Version 1.
3
Page 31
of 41
1.12
Parallel arm with lamp head holder unit
assembly
1.12.1
Fixed lamp head
(128
-0-
21
0)
Required items
Part #
# of items
Description
128
-1-
223
1
Parallel arm
128
-1-
220
1
Bracket
128
-1-
221
1
Side plate R
128
-1-
222
1
Side pl
ate L
128
-1-
943
4
Bushing
s
128
-1-
939
8
Screw
s
PT
-
5 x 12 mm
128
-1-
940
4
Starlock
s
Caps BV 6666
-
03C
Assembly description
Step 1)
Screw one side plate R (128
-1-
221) to the bracket (128
-1-
220) using 4
PT
screws . Assure
that the bracket has the right orientati
on, refer to drawing.
Step 2)
Put the bushings (128
-1-
943) in the holes in both side plates.
Step 3)
Assemble the bracket with the side plate to the parallel
arm;
assuring that the axles from the
parallel arm enters the bushings.
Step 4)
Assemble the side plate L (128
-1-
222) to t
he bracket, so that the bushing enters the axle on
the parallel arm. Screw it to the bracket using 4
PT
screws.
Step 5)
Secure the two 52 x 6 mm
pin bolts
going through the
side plates
R and L with Starlock
Caps on both sides. Use a plastic hammer to prevent the C
aps to be damaged.
