Service Manual Aktilite
CL128
Version 1.
3
Page 29
of 41
1.11.2
D
etachable lamp head (128
-0-
252)
Required items
Part #
# of items
Description
128
-0-
200
1
Lamp head module
128
-0-
212
1
Parallel arm with lamp head holder unit
128
-1-
959
1
Lamp head holder inner right
128
-1-
960
1
Lamp head holder
inner left
128
-1-
963
1
Lamp head holder top cover
128
-1-
964
2
Break shoe
128
-1-
974
2
Break pad spring
128
-1-
973
2
Umbraco screw DIN912 M5×25
128
-1-
975
2
Hexagonal nut DIN934 M5
128
-1-
972
1
Spring lock washer DIN127A M5
128
-1-
976
1
Teflon
-
bronze wash
er (Frimet)
128
-1-
977
1
Security pin DIN1481 Ø4×20
128
-1-
980
1
Umbraco screw DIN912 M5×45
128
-1-
916
1
Circlip
128
-1-
263
2
Crimp pin
128
-1-
956
1
Loctite 243 glue
128
-1-
991
1
Plug UTS6JC104P
128
-1-
136
1
Label Power Plug
