Service Manual Aktilite

CL128

Version 1.

3

Page 19

of 41

Table of Contents

Table of Contents2
Assembly of Aktilite Cl128 Lamp with Parallel Arm3
Material/Equipment3
Tools Needed for the Assembly of Lamp with Fixed Lamp Head3
Tools Needed for the Assembly of Lamp with Detachable Lamp Head3
Ready Tested System Electronics Module (128-0-439) Assembly4
Housing Top Module (128-0-610) Assembly5
Light Module (128-0-750)6
Glue Lenses6
Positioning Arm Module (128-0-400) Assembly7
Fixed Lamp Head7
Detachable Lamp Head8
Housing Bottom Module (128-0-820)9
Housing Back Module (128-0-810) Assembly9
Lamp Head Module (128-0-200) Assembly10
Fixed Lamp Head10
Detachable Lamp Head11
Disassemly and Assembly of the Lamp Slide Series12
Stop Block Module (Ts1-0-250) Assembly27
Lamp Including Parallel Arm Assembly28
Fixed Lamp Head (128-0-250)28
Detachable Lamp Head (128-0-252)29
Parallel Arm with Lamp Head Holder Unit Assembly31
Fixed Lamp Head (128-0-210)31
Detachable Lamp Head (128-0-212)32
Labels Placement Description33
Replacing the DC Power Plug34
Assembly of Aktilite Cl128 Power Supply35
Material/Equipment35
Ps Electronics Module (128-0-330) Assembly36
Ps Housing Modulea (128-0-310) Assembly37
Ps Housing Moduleb (128-0-320) Assembly38
Power Supply (128-0-300) Assembly39
Error Codes40
