Service Manual Aktilite CL128
Version 1. 3 Page 41 of 41
1. Disconnect the mains ca ble for at least 20 seconds
2. Reconnect the mains cable
3. Check all cables and connections
4. Switch on and check if the lamp can be used as normal
5. If the error persists, refer to the table below
Aktilite CL128 Error Codes
NOTE: Refer to the instructions above before using the table
Error
Code
Possible Causes Description
1101 Device internal error POST FLASH (Program memory) error.
1102 Device internal error POST EEPROM (System parameters) error.
1103 Device internal error POST RAM (Static memory) error.
1 104 Key was pressed during switch - on
self - test
or
Device internal error
POST key stuck error.
1105 Device internal error POST too low enclosure temperature error.
1107 Device internal error POST too low LED driver temperature error.
1109 Device internal error POST too big variation LED driver temperatures error.
1110 Device internal error POST too low LED array temperature error.
1112 Device internal error POST too big variation LED array temperatures error.
1117 The lamp has reached the maximum
allow ed number of illumination hours.
Need to recalibrate or replace the light source.
1206 Obstruction of cooling air inlet/outlet
or
Device internal error
POST too high enclosure temperature error.
1208 Obstruction of cooling air inlet/outlet
or
Device inte rnal error
POST too high LED driver temperature error.
1211 Obstruction of cooling air inlet/outlet
or
Device internal error
POST to high LED array temperature error.
2105 Device internal error Self - test too low enclosure temperature error.
2107 Device internal error Self - test too low LED driver temperature error.
2109 Device internal error Self - test too big variation LED driver temperatures error.
2110 Device internal error Self - test too low LED array temperature error.
2112 Device internal error Sel f- test too big variation LED driver temperatures error.
2206 Obstruction of cooling air inlet/outlet
or
Device internal error
Self - test too high enclosure temperature error.
2208 Obstruction of cooling air inlet/outlet
or
Device internal error
Self - te st too high LED driver temperature error.
2211 Obstruction of cooling air inlet/outlet
or
Device internal error
Self - test too high LED array temperature error.
2213 Device internal error Self - test watchdog error. The software has been restarted.
2214 De vice internal error Self - test too high LED current for OFF mode.
2215 Device internal error Self - test too high LED current for GUIDE LIGHT mode.
2216 Device internal error Self - test too high or too low LED current for FULL LIGHT mode.
