5 System menu
System menu enables to view the information about
– device modification
– firmware version
– cycle time
– I/O status
and other device parameters.
The application can be interrupted by using the menu item Device>Program>Run/Stop.
When the setting is changed it requires a reboot to take effect. When the application is
interrupted all parameters exept network variables are available via Modbus in slave mode
and via system menu. The menu is password protected, with can be set or changed in ALP
or using the menu. If the password is lost, it can be changed by loading a new application.
Press the button for 3 seconds to access the menu.
Press the button for 3 seconds to exit the menu.
5.1 Menu navigation
There are editable and not editable display elements thus the display can be used in view or
edit mode.
View mode
To move between lines use and buttons.
To enter the selected level use and to exit.
Edit mode
Press button to enter the edit mode from the current display. The first editable element
starts flashing. Use buttons and to change the parameter. Use following button
combinations to move between characters:
− + – one character to the left
− + – one character to the right.
To save the new value and exit Edit mode use .
To reset a parameter to its original value and exit Edit mode use .
To save the new value staying in the Edit mode use . The next editable parameter will be
displayed selected.
The last changed parameter will be shown next time when the edit mode is entered.
