2 Specifications
Table 2.1 General specification
Device PR200-230.1
PR200-230.2
PR200-230.4
PR200-24.1
PR200-24.2
PR200-24.4
Power supply
230 (94…264) V AC;
50 (47…63) Hz
24 (19…30) V DC
Power consumption, max
10 VA
17 VA
10 W
10 W
Galvanic isolation
2830 V
1780 V
Appliance class
II
III
Integrated voltage source -
24±3 V DC
100 mA
- -
Galvanic isolation
-
1780 V
-
-
Inputs
Digital
8
Analog *
-
4
-
4
Outputs
Digital (relay)
6
8
6
8
Analog
-
2
-
2
Programming
Software
akYtec ALP
Interface
Mini USB 2.0
Program cycle, min
1 ms
Function buttons
6
LEDs
F1 (green), F2 (red), programmable
LCD display
2x 16 digits, backlight adjustable
Language
English
Connection to RS485 Network
2-pole plug-in terminal block
Protocols
Modbus RTU/ASCII (Master/Slave)
Baud rate
9.6…115.2 kbit/s
Interface card
PR-IC485 (max. 2)
Galvanic isolation
1500 V
Dimensions
123 x 108 x 58 mm
Mounting
DIN rail (35 mm)
Weight
approx. 350 g
Material
Plastic
* Analog inputs AI1…AI4 can also be configured as digital inputs
Table 2.2 Digital inputs
Device PR200-230.1
PR200-230.2
PR200-230.4
PR200-24.1
PR200-24.2
PR200-24.4
Input signal Switch contact
Switch contact
PNP with open collector
Digital signals -3…+30 VDC
Input voltage
230 V AC
24 V DC
Input voltage, max
264 V AC
30 V DC
Logical 1
159…264 V (0.75…1.5 mA)
15…30 V (5 mA)
Logical 0
0…40 V (0…0.5 mA)
-3…+5 V (0…1 mA)
Pulse length, min
50 ms
2 ms
Response time, max
100 ms
30 ms
Galvanic isolation
in groups of 4 (1-4, 5-8)
Test voltage between
input groups
1780 V
Test voltage against
other circuits
2830 V
