Akytec PR200 - Environmental Conditions

Specifications
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de
7
Table 2.7 Real-time clock
Accuracy
±3 s/day (25°C)
Correction
-2.75…+5.5 min/month
Backup, min
8 years
Backup battery
CR2032
2.1 Environmental conditions
The relay is designed for natural convection cooling. It should be taken into account when
choosing the installation site.
The following environment conditions must be observed:
− clean, dry and controlled environment, low dust level
− closed non-hazardous areas, free of corrosive or flammable gases
Table 2.1
Conditions
Permissible range
Ambient operating temperature
-20…+55°C
Storage temperature
-25…+55°C
Relative humidity
up to 80% (at +25°C, non-condensing)
IP Code
IP20
Altitude
up to 2000 m above see level
EMC immunity
conforms to IEC 61000-6-2
EMC emission
conforms to IEC 61000-6-4
