System menu
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de
18
Analog
Status of each analog input is displayed as a scaled measured value of REAL32
type. The lower and the upper limits can be set in the menu item
Inputs>Analog>Scale.
The type of input signal can be selected in the menu item Inputs>Analog>Sensor.
The menu item Inputs>Analog>Filter enables to set the time constant for the filter
within the range of 0.01…60 s with the increment of 0.001 s.
Outputs
Digital
Status of digital outputs is displayed as a bitmask: 0 for OFF state, 1 for ON state.
The first bit in the mask corresponds to output 1.
Analog
Status of each analog output is displayed as a REAL32 value within the range of
0…1.
Interfaces
Inteface configuration depends on the interface mode, Master or Slave.To set interface
parameters use the menu item Interfaces and select the interface.
Slave mode
o Settings
Baud rate
Data bits
Parity
Stop bits
o Protocol
Address
Master mode
o Settings
Baud rate
Data bits
Parity
Stop bits
o Protocol
List of configured devices (see 4.5 ‘Master mode’)
Address
Polling cycle (ms)
Time-out (ms)
Retries, max.
Time between frames (see 4.5 ‘Master mode’)
