474911_d 43
Help in case of malfunctions
Once a year
■
Replace the spark plug (see engine operating
manual).
■
Grease the transport auger.
■
Change the engine oil.
9.2 Greasing the transport auger (47)
Pump approx. 2-3 strokes of multi-purpose
grease into grease nipple (47/1) using a grease
gun.
9.3 Servicing the travel and auger drives
(09)
WARNING! Risk of injury during mainte-
nance work. Improper maintenance can result in
serious injury and in damage to the appliance.
■
Adjust the Bowden cable only with the engine
switched off.
■
Stop the engine if the travel/auger drive can-
not be switched off.
■
Do not try to carry out repairs yourself and
contact a specialist workshop immediately.
NOTE Moisture in the Bowden cable can re-
sult in corrosion or freezing. A damaged Bowden
cable must be replaced.
Adjust Bowden cable
If the travel/auger drive cannot be engaged with
the engine running, the respective Bowden cable
must be adjusted.
1. Loosen lock nut (09/2).
2. Turn the adjuster on the Bowden cable (09/1)
in the direction of the arrow (09/a) until the
Bowden cable no longer sags (is slightly ten-
sioned). While turning the adjuster, hold the
cable so that it does not become twisted.
3. Tighten lock nut (09/2) (09/b).
4. To check the setting, start the engine and
switch on the travel/auger drive.
5. If the travel/auger drive still cannot be proper-
ly engaged, the appliance must be taken to a
specialist workshop.
9.4 Replacing the shear pins (31, 48)
For the safety of the operator and appliance, the
shear pins (31/1) can break after a blockage of
the transport auger.
NOTE Replace broken shear pins with OEM
spare parts. Use of non-approved spare parts
can result in serious damage to the appliance!
1. Switch off the appliance and remove the
spark plug connector.
2. Remove the cotter pin (48/1) (48/a).
3. Pull out the damaged shear pins (48/2) (48/
b).
4. Inspect the shaft for damage.
5. Insert a new shear pin and secure with cotter
pin.
9.5 Fine adjustment of the height of the
screw conveyor [760 TE only] (49)
By adjusting the screw (49/1), a fine adjustment
can be carried out to raise or lower the transport
auger and the plough.
The operating mode lever (02/23) adjusts the
screw:
■
The figure (49) shows the position of the
screw for "Packed Snow". Slightly raise the
snow blower in this position.
■
In the "Transport" position, the axle is fixed.
■
For operation, the operating mode lever must
be set to "Normal".
9.6 Adjusting the tension of the chains (50)
The tension of the chains can be adjusted by
tightening the nuts (50/1) on the hook (50/2).
Each caterpillar can be adjusted.
10 HELP IN CASE OF MALFUNCTIONS
CAUTION! Risk of injury. Sharp-edged
and moving appliance parts can lead to injury.
■
Always wear protective gloves during mainte-
nance, care and cleaning work!
■
Switch off the engine and check that the en-
gine is at a standstill!
■
Remove the spark plug connector!
NOTE For malfunctions that are not listed in
this table or that you cannot resolve yourself,
please contact our customer service.
Malfunction Remedy
Engine does not
start.
Fill with petrol.
Move the throttle lever to
the “Start” position.
Switch on the choke and
press the primer button.
Service the spark plug.
