Alcatel-Lucent 1830 PSS-16 - Lpbkline

Alarm Data Value/Meaning
Alarm Entity Type 112SCA1 and 112SCX10 (line side only):
OTU4
11STMM10 (client side only) and 4DPA4:
OTU1
43STA1P and 43STX4P: OTU3
OPS: OCH
All amplifiers: OTS
All other AIDs: OTU2
Description Incoming Payload
Corrective Action Proceed to “LOS-P” (p. 2-172).
LPBKLine
Alarm Data Value/Meaning
Severity Level Not alarmed
AID Type 112SA1L-shelf-slot-{L1, C1}
112SCA1-shelf-slot-{L1, C1}
112SCX10-shelf-slot-{L1, {C1-10}}
112SX10L-shelf-slot-{L1, {C1-10}}
11DPE12-shelf-slot-{L{1-2},C{1-12}}
11DPE12E-shelf-slot-{L{1-2},C{1-12}}
11QPA4-shelf-slot-{L{1-4},C{1-4}}
11STAR1-shelf-slot-{L1, C1}
11STMM10-shelf-slot-{L1, C{1-10}}
11STGE12-shelf-slot-{L1, C{1-12}}
43SCX4-shelf-slot-{L1, {C1-10}}
43STA1P-shelf-slot-{L1, C1}
43STX4-shelf-slot-{L1, C1-C4}
43STX4P-shelf-slot-{L1, C1-C4}
4DPA2-shelf-slot-{L{1-2}, C{1-2}}
4DPA4-shelf-slot-{L{1-2}, C{1-4}}
Effect on Service NSA
Alarm and condition details LOS-P
....................................................................................................................................................................................................................................
....................................................................................................................................................................................................................................
1830 PSS-36/PSS–32/PSS-16/PSS-4
8DG60888CAAA Release 3.6.0 and 3.6.1
Issue 1 June 2011
1-113
