OmniSwitch Backup Power Shelf/System (BPS) Specifications
OmniSwitch Backup Power Shelf/System (BPS) January 2013 page 4-3
Specifications
1
The OmniSwitch Backup Power Shelf/System (BPS) ships with a factory-attached mounting plate that
can be removed onsite to reduce the overall unit height to 1RU.
2
Fully populated weight includes all installable power supplies.
3
900W system power requires two 450W OS-BPS-S power supplies to be installed and operating in the
OS-BPS chassis.
*Note On Chassis Versus Ambient Temperatures. Chassis temperature refers to the sensor reading of
the internal chassis temperature (threshold or danger). Ambient temperature refers to the temperature of
the room and are approximations. The ambient temperature will be less than the chassis temperature and
will vary for each model due to different airflow characteristics.
OmniSwitch Backup Power Shelf/System (BPS) Chassis Specifications
Chassis Width (with brackets)
Chassis Width (without brackets)
48.2 cm (19 inches)
43.3 cm (17.05 inches)
Chassis Height 4.4 cm (1.73 inches or 1RU)
Overall Unit Height with Factory-Attached Mounting Plate
1
6.67 cm (2.625 inches or 1.5RU)
Overall Chassis Depth 46.04 cm (18.125 inches)
Chassis Weight (empty) 4.4 kg (9.68 lbs)
Chassis Weight (fully populated)
2
12.85 kg (28.34 lbs)
System Power Supply Bays 2
PoE Power Supply Bays 3
Compatible Power Supplies (System Power)
Compatible Power Supplies (PoE Power)
OS-BPS-S (OS-PS-450W-A)
OS-BPS-P (CP2000AC54TEP-AL)
Maximum Power (PoE) 6000W
Maximum Power (System)
3
900W
Operating Temperature (Tmra): 0°C to 45°C (32°F to 113°F)
Storage Temperature -10°C to +70°C (14°F to 158°F)
Humidity (Operating) 5% to 95% non-condensing
Humidity (Non-Operating) 5% to 95% non-condensing
