Wide Operation
In WIDE the user is able to crossfade
between, or combine two scenes which
are 24 (48) channels wide.
A scene is set up using the PRESET A
and PRESET B faders. The PRESET A
faders control channels 1 -12 (1 - 24).
The PRESET B faders control channels
13 - 24 (25 - 48).
This scene is then stored temporarily by
pressing the PRESET CONTROL button.
A second scene can then be set up on the
PRESET A and PRESET B faders.
The A MASTER and B MASTER faders
can then be used to crossfade between
the two scenes.
The PRESET CONTROL button is used
to control which master has control of the
PRESET channel faders, and the stored
scene.
The GRAND MASTER is used to control
the final output levels from the desk.
The CROSSFADE control is used to
determine the crossfade time between the
two scenes.
Setting up for Wide Operation
1. If the desk is not already in PRESET
Mode, press and hold the MODE
button for 1 second. The PRESET
light above the MODE button will
come on.
2. Ensure WIDE is active. On first
invoking WIDE or re-entering WIDE,
the PRESET faders will be assigned
to the A MASTER, and the stored
scene assigned to the B MASTER.
The lights next to the PRESET
CONTROL button will indicate this (A
FADERS, B STORED). The
temporarily stored scene will be
cleared.
Page 14 Alcora 73-700-00 Issue 2
Preset Mode
