49
(3.6.4.3) HH (Hi-Hat), C1 – C4 (Cymbals)
Parameter Description Value Range
Curve
This determines how a sound’s volume is affected by
how hard you strike it—that is, how responsive the
trigger’s dynamics are to changes in your playing.
Linear
Log 1
Log 2
Log 3
Log 4
Exp 1
Exp 2
Exp 3
Exp 4
Spline 1
Spline 2
Spline 3
Spline 4
Offset
Constant
Bow Sensitivity n/a This adjusts the sensitivity for the bow
(outer half of the cymbal) to have a
higher response with lighter hits.
1.0 – 32.0
Edge Sensitivity n/a This adjusts the sensitivity for the
edge (rim area, furthest from the
center) to have a higher response with
lighter hits.
1.0 – 32.0
Threshold n/a This sets the minimum trigger velocity
required to pass a signal through. Any
values below this setting will not be
played. This is used to filter out
noise/vibrations in the environment,
such as if the kit is next to a
speaker/subwoofer.
1 – 127
