Alesis PRIME - Page 66

66
(6.0) Appendix
(6.1) Technical Specifications
Trigger Inputs
1/4” (6.35 mm)
Type: Balanced 1/4” TRS or unbalanced 1/4” TS
Frequency Response: 20 Hz – 20 kHz (+0.2 dB)
Dynamic Range: 111 dB (A-weighted)
Signal-to-Noise Ratio: 110 dB (1 kHz, +4 dBu, A-weighted)
THD+N: 0.003% (1 kHz, +4 dBu, -1 dBFS)
Max Input Level: +20 dBu
Input Impedance: 1 MΩ
Sensitivity: -20 dBu
Gain Range: 40 dB
Main Outputs (XLR) Type: Balanced XLR
Frequency Response: 20 Hz – 20 kHz (+0.2 dB)
Dynamic Range: 113 dB (A-weighted)
THD+N: 0.001% (1 kHz, -1 dBFS)
Maximum Output Level: +20 dBu
Output Impedance: 100 Ω
Audio Outputs
(1/4”, 6.35 mm)
Type: Impedance-balanced 1/4” TRS
Frequency Response: 20 Hz – 20 kHz (+0.2 dB)
Dynamic Range: 113 dB (A-weighted)
THD+N: 0.003% (1 kHz, -1 dBFS)
Maximum Output Level: +20 dBu
Output Impedance: 100 Ω
Headphone Output
(1/4”, 6.35 mm)
Type: (1/8” / 3.5 mm TRS)
Frequency Response: 20 Hz – 20 kHz (+0.2 dB)
Dynamic Range: 112 dB (A-weighted)
THD+N: 0.008% (1 kHz, 10mW per channel into 32)
Maximum Output Level: +20 dBu (unloaded)
Power Output: 100 mW RMS (per channel into 32 Ω)
Output Impedance: 32 Ω
Power Input Voltage: 19V 3.42A Center Positive
Dimensions
(width x depth x height)
14.05” x 8.97” x 4.09”
357 x 228 x 104 mm
Weight 6.35 lbs.
2.88 kg
Specifications are subject to change without notice.
