8301 IP Paging Adapter & Scheduler
support@algosolutions.com
5. Press DTMF Extension *11 for Zone 11
Note
DTMF codes for zones 10 and higher start with an “*”
All DTMF codes and respective zones are available in Advanced Settings
→
Advanced Multicast.
Zone Selection Tone
Only visible when ‘Zone Selection Mode’ is set to ‘DTMF Selectable Zone’. The tone played over the phone to prompt
the user to select a zone to multicast to.
Transmitter Single Zone
The zone that multicast stream will be sent to by default. If ‘DTMF Selectable Zone’ is chosen above, this setting will
not apply to Paging, since the zone now must be dynamically selected per call via DTMF. However, the specified
Transmitter ‘Single Zone’ setting is still used for any multicast events triggered by the Ring, analog input, or the relay
input.
Note
The Transmitter Single Zone is the default zone used for any multicast actions unless an option is available for a
custom zone with specific parameters.
Speaker Playback Zones
The Speaker Playback Zones allows the Transmitter device to play audio for selected zones only. This is useful if using
the DTMF Selectable Zone mode (or More Page Extensions per zone) with the intention of making the Transmitter unit
a member of only certain zones. In this case, the Transmitter does not participate in the Zone, but it transmits certain
traffic.
Expanded Speaker Playback Zones
Up to 50 zones can be shown and are only visible when ‘Basic and Expanded Zones’ is selected.
DTMF Settings
Zone Selection Tone
This is the prompt to select a zone. This may be used as an interactive voice response (IVR) menu by uploading a
custom audio file through System → File Manager in the Tones folder. Each zone may use a different tone. This can be
configured in Advanced Settings → Advanced Multicast.
Two-Digit Selection
When enabled, all DTMF Selectable Zones will require two digits. As a result, Basic Zones must be prefixed with ‘0’ and
Expanded Zones will no longer need to be prefixed with ‘*’.
