802.1Q Virtual LAN
VLAN Mode
Enables or Disables VLAN Tagging. VLAN Tagging is the networking standard that supports Virtual LANs (VLANs) on an
Ethernet network. The standard defines a system of VLAN tagging for Ethernet frames and the accompanying
procedures to be used by bridges and switches in handling such frames. The standard also provides provisions for a
quality-of-service prioritization scheme commonly known as IEEE 802.1p and defines the Generic Attribute
Registration Protocol.
VLAN ID
Specifies the VLAN to which the Ethernet frame belongs. A 12-bit field specifying the VLAN to which the Ethernet
frame belongs. The hexadecimal values of 0x000 and 0xFFF are reserved. All other values may be used as VLAN
identifiers, allowing up to 4094 VLANs. The reserved value 0x000 indicates that the frame does not belong to any
VLAN; in this case, the 802.1Q tag specifies only a priority and is referred to as a priority tag.
VLAN Priority
Sets the frame priority level. Otherwise known as Priority Code Point (PCP), VLAN Priority is a 3-bit field which refers
to the IEEE 802.1p priority. It indicates the frame priority level. Values are from 0 (lowest) to 7 (highest).
802.1X Port-based Network Access Control
802.1x Authentication
Credentials to access LAN or WLAN that have 802.1X network access control (NAC) enabled. This information will be
available from the IT Administrator.
Authentication Mode
Select the desired authentication mode.
Anonymous ID
If configured, the 8301 will send the anonymous ID to the authenticator instead of the 802.1X client username.
ID
The ID should contain a string identifying the IEEE 802.1X authenticator originating the request.
Password
Enter the password.
