SEMICONDUCTOR DATA
1) M5218FP (XA0068)
Power Supply Plus
Output 2
Inverting Input 2
Non Inverting Input 2
8
7
6
5
Output 1
Inverting Input 1
Non Inverting Input 1
Power supply Minus
1
2
3
4
Dual Low Noise
Operational Amplifiers
2) NJM7808FA (XA0102)
1. OUTPUT
2. COMMON
3. INPUT
Pin Assignment
123
3) TC4S66F (XA0115)
Bilateral Switch
