PARTS LIST

Ref.

Qty

No.

DR-135 DR-235 DR-435

CU3111 Chip C. C1608JB1C104KT-N 1 1 1

CU3049 Chip C. C1608JB1E153KT-NS 1 1 1

CU3111 Chip C. C1608JB1C104KT-N 1 1 1

CU3023 Chip C. C1608CH1H101JT-AS 1 1 1

CU3043 Chip C. C1608JB1H472KT-NS 1 1 1

CU3111 Chip C. C1608JB1C104KT-N 1 1 1

C10

CU3043 Chip C. C1608JB1H472KT-NS 1 1 1

C11

CU3043 Chip C. C1608JB1H472KT-NS 1 1 1

C12

CU3101 Chip C. C1608JB1C473KT-NS 1 1 1

C13

CS0049 Chip tantalum TMCSA1C105MTR 1 1 1

C14

CU3014 Chip C. C1608CH1H180JT-AS 1 1 1

C15

CU3014 Chip C. C1608CH1H180JT-AS 1 1 1

C16

CU3035 Chip C. C1608JB1H102KT-AS 1 1 1

C17

CS0372 Chip tantalum TMCMB1C106MTR 1 1 1

C18

CU3035 Chip C. C1608JB1H102KT-AS 1 1 1

C19

CU3111 Chip C. C1608JB1C104KT-N 1 1 1

C20

CU3101 Chip C. C1608JB1C473KT-NS 1 1 1

C21

CU3047 Chip C. C1608JB1H103KT-N 1 1 1

C22

CU3035 Chip C. C1608JB1H102KT-AS 1 1 1

C23

CU3047 Chip C. C1608JB1H103KT-N 1 1 1

C24

CU3035 Chip C. C1608JB1H102KT-AS 1 1 1

C25

CU3035 Chip C. C1608JB1H102KT-AS 1 1 1

C26

CU3035 Chip C. C1608JB1H102KT-AS 1 1 1

C27

CU3035 Chip C. C1608JB1H102KT-AS 1 1 1

C28

CS0394 Chip tantalum TMCMB0J476MTR 1 1 1

C29

CS0049 Chip tantalum TMCSA1C105MTR 1 1 1

C30

CS0372 Chip tantalum TMCMB1C106MTR 1 1 1

C31

CU3047 Chip C. C1608JB1H103KT-N 1 1 1

C32

CU3047 Chip C. C1608JB1H103KT-N 1 1 1

CN1

UE0398 Connector 20-5082-3010-17-100 1 1 1

CN2

UE0398 Connector 20-5082-3010-17-100 1 1 1

CN3

UE0035 Mic Connector FM214-8SMPY 1 1 1

XL0069 Chip LED FA1111C-TR 1 1 1

XL0077 Chip LED FA1111C-TR C,D,ERANK 1 1 1

XL0069 Chip LED FA1111C-TR 1 1 1

XL0077 Chip LED FA1111C-TR C,D,ERANK 1 1 1

XD0254 Chip Diode 1SS355 TE17 1 1 1

XD0291 Chip Diode MA729-TX 1 1 1

D10

XD0135 Chip Diode U1BC44 TE12R 1 1 1

D11

XL0077 Chip LED FA1111C-TR C,D,ERANK 1 1 1

D12

XD0165 Chip Diode UDZSTE-17 5.1B 1 1 1

D13

XD0165 Chip Diode UDZSTE-17 5.1B 1 1 1

D14

XD0291 Chip Diode MA729-TX 1 1 1

D15

XD0165 Chip Diode UDZSTE-17 5.1B 1 1 1

D16

XD0291 Chip Diode MA729-TX 1 1 1

D17

XD0291 Chip Diode MA729-TX 1 1 1

D19

XD0363 Chip Diode RLS-73TE-11 1 1 1

IC1

XA0818 CPU M38267M8L269GP 1 1 1

IC2

XA0604 IC 24LC32AT-I/SN 1 1 1

IC4

XA0620 IC S-80845ALMP-EA9-T2 1 1 1

IC5

XA0675 IC L88MS05TLL-TL 1 1 1

JK1

UJ0047 Jack HSJ2013-01-120 1 1 1

JP3

Wire #30AH1-040-H1 1 1 1

T,TG,E,EG

LCD1

EL0049 LCD TTR3626 UPTDHN 1 1 1

XU0029 Chip Transistor DTC114YUA T106 1 1 1

XU0131 Chip Transistor DTC114EUA T106 1 1 1

XT0110 Chip Transistor 2SA1036K T146Q 1 1 1

XU0131 Chip Transistor DTC114EUA T106 1 1 1

XT0095 Chip Transistor 2SC4081 T106R 1 1 1

XT0061 Chip Transistor 2SB1132T 100Q 1 1 1

XU0029 Chip Transistor DTC114YUA T106 1 1 1

XU0148 Chip Transistor DTC144EUA T106 1 1 1

Q10

XU0131 Chip Transistor DTC114EUA T106 1 1 1

Q11

XU0112 Chip Transistor DTA114YUA T106 1 1 1

Q12

XU0112 Chip Transistor DTA114YUA T106 1 1 1

Q13

XU0112 Chip Transistor DTA114YUA T106 1 1 1

RK3054 Chip R. MCR03EZHJ223 1 1 1

RK3001 Chip R. MCR03EZHJ000 - 1 -

RK3054 Chip R. MCR03EZHJ223 1 1 1

RK3050 Chip R. MCR03EZHJ103 1 1 1

RK3023 Chip R. MCR03EZHJ560 1 1 1

RK3038 Chip R. MCR03EZHJ102 1 1 1

R10

RK3032 Chip R. MCR03EZHJ331 1 1 1

Parts No. Parts Name VerDescription

Ref.

Qty

No.

DR-135 DR-235 DR-435

R11

RK3046 Chip R. MCR03EZHJ472 1 1 1

R13

RK3001 Chip R. MCR03EZHJ000 1 - 1 E,EG

R14

RK3048 Chip R. MCR03EZHJ682 1 1 1

R15

RK3001 Chip R. MCR03EZHJ000 - - 1

R16

RK3001 Chip R. MCR03EZHJ000 1 1 1 T,TG

R19

RK3062 Chip R. MCR03EZHJ104 1 1 1

R20

RK3046 Chip R. MCR03EZHJ472 1 1 1

R21

RK3030 Chip R. MCR03EZHJ221 1 1 1

R22

RK3038 Chip R. MCR03EZHJ102 1 1 1

R23

RK3064 Chip R. MCR03EZHJ154 1 1 1

R24

RK3050 Chip R. MCR03EZHJ103 1 1 1

R25

RK3050 Chip R. MCR03EZHJ103 1 1 1

R26

RK3050 Chip R. MCR03EZHJ103 1 1 1

R27

RK3050 Chip R. MCR03EZHJ103 1 1 1

R28

RK3038 Chip R. MCR03EZHJ102 1 1 1

R29

RK3038 Chip R. MCR03EZHJ102 1 1 1

R30

RK3038 Chip R. MCR03EZHJ102 1 1 1

R31

RK3038 Chip R. MCR03EZHJ102 1 1 1

R32

RK3044 Chip R. MCR03EZHJ332 1 1 1

R33

RK3034 Chip R. MCR03EZHJ471 1 1 1

R34

RK3047 Chip R. MCR03EZHJ562 1 1 1

R35

RK3052 Chip R. MCR03EZHJ153 1 1 1

R36

RK3062 Chip R. MCR03EZHJ104 1 1 1

R37

RK3049 Chip R. MCR03EZHJ822 1 1 1

R38

RK3050 Chip R. MCR03EZHJ103 1 1 1

R39

RK3058 Chip R. MCR03EZHJ473 1 1 1

R40

RK3062 Chip R. MCR03EZHJ104 1 1 1

R41

RK3026 Chip R. MCR03EZHJ101 1 1 1

R42

RK3050 Chip R. MCR03EZHJ103 1 1 1

R43

RK3050 Chip R. MCR03EZHJ103 1 1 1

R44

RK3026 Chip R. MCR03EZHJ101 1 1 1

R45

RK3050 Chip R. MCR03EZHJ103 1 1 1

R47

RK3038 Chip R. MCR03EZHJ102 1 1 1

R48

RK3038 Chip R. MCR03EZHJ102 1 1 1

R49

RK3038 Chip R. MCR03EZHJ102 1 1 1

R50

RK3070 Chip R. MCR03EZHJ474 1 1 1

R51

RK3038 Chip R. MCR03EZHJ102 1 1 1

R52

RK3038 Chip R. MCR03EZHJ102 1 1 1

R53

RK3062 Chip R. MCR03EZHJ104 1 1 1

R54

RK3050 Chip R. MCR03EZHJ103 1 1 1

R55

RK3074 Chip R. MCR03EZHJ105 1 1 1

R56

RK3050 Chip R. MCR03EZHJ103 1 1 1

R57

RK3066 Chip R. MCR03EZHJ224 1 1 1

R58

RK3034 Chip R. MCR03EZHJ471 1 1 1

R59

RK3026 Chip R. MCR03EZHJ101 1 1 1

R60

RK3034 Chip R. MCR03EZHJ471 1 1 1

R61

RK3074 Chip R. MCR03EZHJ105 1 1 1

R62

RK3050 Chip R. MCR03EZHJ103 1 1 1

R63

RK3026 Chip R. MCR03EZHJ101 1 1 1

R64

RK3046 Chip R. MCR03EZHJ472 1 1 1

R65

RK3026 Chip R. MCR03EZHJ101 1 1 1

R66

RK3050 Chip R. MCR03EZHJ103 1 1 1

R67

RK3026 Chip R. MCR03EZHJ101 1 1 1

R68

RK3050 Chip R. MCR03EZHJ103 1 1 1

R69

RK3046 Chip R. MCR03EZHJ472 1 1 1

R70

RK3062 Chip R. MCR03EZHJ104 1 1 1

R71

RK3072 Chip R. MCR03EZHJ684 1 1 1

R72

RK3050 Chip R. MCR03EZHJ103 1 1 1

R73

RK3032 Chip R. MCR03EZHJ331 1 1 1

R74

RK3026 Chip R. MCR03EZHJ101 1 1 1

R75

RK3046 Chip R. MCR03EZHJ472 1 1 1

R76

RK3032 Chip R. MCR03EZHJ331 1 1 1

R77

RK3028 Chip R. MCR03EZHJ151 1 1 1

R79

RK3038 Chip R. MCR03EZHJ102 1 1 1

R80

RK3038 Chip R. MCR03EZHJ102 1 1 1

R82

RK3050 Chip R. MCR03EZHJ103 1 1 1

R83

RK3038 Chip R. MCR03EZHJ102 1 1 1

R84

RK0008 Chip R. ERJ6GEYJ330V 1 1 1

R85

RK3046 Chip R. MCR03EZHJ472 1 1 1

R86

RK3050 Chip R. MCR03EZHJ103 1 1 1

R87

RK3054 Chip R. MCR03EZHJ223 1 1 1

R88

RK3050 Chip R. MCR03EZHJ103 1 1 1

R89

RK3058 Chip R. MCR03EZHJ473 1 1 1

R90

RK3058 Chip R. MCR03EZHJ473 1 1 1

R91

RK3050 Chip R. MCR03EZHJ103 1 1 1

R92

RK3032 Chip R. MCR03EZHJ331 1 1 1

R95

RK3062 Chip R. MCR03EZHJ104 1 1 1

R96

RK4014 Chip R. ERJ12YJ100U 1 1 1

R97

RK3050 Chip R. MCR03EZHJ103 1 1 1

RE1

UR0015 Dial RH90N74E20-A90770 1 1 1

RL1

UL0020 Relay ATQ209 1 1 1

VerParts NameParts No. Description

CPU

MACL04GG
