Alinco DR-435 - Main Unit

33
Ref.
Qty
No.
DR-135 DR-235 DR-435
SW1
UU0015Z Switch EVQPPXA25 1 1 1
SW2
UU0015Z Switch EVQPPXA25 1 1 1
SW3
UU0015Z Switch EVQPPXA25 1 1 1
SW4
UU0015Z Switch EVQPPXA25 1 1 1
SW5
UU0015Z Switch EVQPPXA25 1 1 1
SW6
UU0015Z Switch EVQPPXA25 1 1 1
SW7
UU0015Z Switch EVQPPXA25 1 1 1
VR1
RV0035 Variable EVUF2JFK4B14 1 1 1
W1
UX1270 Wire WIRE DR235 W1 1 1 1
X1
XQ0131 Xtal CSA310/3.6864MHz 1 1 1
TL0024 DIFFUSION SHEET 135 1 1 1
YZ0042 CEMENT G17 / 1G 1 1 1
ST0068 DIAL FITTING 1 1 1
FG0305 LCD RUB.CONNECT. 135 1 1 1
TL0023 REFLECTION DR135 1 1 1
DG0037 LCD LIGHT DR135 1 1 1
FM0034 MIC GND PLATE 1 1 1
FP0034 MIC SPACER DR110 1 1 1
ST0064 LCD HOLDER DR135 1 1 1
Ref.
Qty
No.
DR-135 DR-235 DR-435
C101
CU3047 Chip C. C1608JB1H103KT-N 1
C102
CU3047 Chip C. C1608JB1H103KT-N 1
C103
CS0049 Chip tantalum TMCSA1C105MTR 1
C104
CU3047 Chip C. C1608JB1H103KT-N 1
C105
CS0394 Chip tantalum TMCMB0J476MTR 1
C106
CU3051 Chip C. C1608JB1E223KT-NS 1
C107
CU3111 Chip C. C1608JB1C104KT-N 1
C108
CU3047 Chip C. C1608JB1H103KT-N 1
C109
CS0216 Chip tantalum TMCMB1A106MTR 1
C110
CU3047 Chip C. C1608JB1H103KT-N 1
C111
CU3047 Chip C. C1608JB1H103KT-N 1
C112
CU3047 Chip C. C1608JB1H103KT-N 1
C113
CU3047 Chip C. C1608JB1H103KT-N 1
C114
CU3047 Chip C. C1608JB1H103KT-N 1
C115
CU3047 Chip C. C1608JB1H103KT-N 1
C116
CU3047 Chip C. C1608JB1H103KT-N 1
C117
CU3047 Chip C. C1608JB1H103KT-N 1
C118
CU3049 Chip C. C1608JB1E153KT-NS 1
C119
CU3051 Chip C. C1608JB1E223KT-NS 1
C120
CU3021 Chip C. C1608CH1H680JT-AS 1
C121
CU3005 Chip C. C1608CH1H040CT-AS 1
C122
CU3002 Chip C. C1608CH1H010CT-AS 1
C123
CU3015 Chip C. C1608CH1H220JT-AS 1
C124
CU3040 Chip C. C1608JB1H272KT-NS 1
C125
CU3044 Chip C. C1608JB1H562KT-NS 1
C126
CU3038 Chip C. C1608JB1H182KT-AS 1
C127
CU3041 Chip C. C1608JB1H332KT-NS 1
C129
CU3111 Chip C. C1608JB1C104KT-N 1
C130
CS0049 Chip tantalum TMCSA1C105MTR 1
C132
CU3035 Chip C. C1608JB1H102KT-AS 1
C133
CU3005 Chip C. C1608CH1H040CT-AS 1
C134
CU3042 Chip C. C1608JB1H392KT-NS 1
C135
CU3044 Chip C. C1608JB1H562KT-NS 1
C137
CU3017 Chip C. C1608CH1H330JT-AS 1
C138
CS0049 Chip tantalum TMCSA1C105MTR 1
C139
CU3017 Chip C. C1608CH1H330JT-AS 1
C140
CU3017 Chip C. C1608CH1H330JT-AS 1
C141
CU3111 Chip C. C1608JB1C104KT-N 1
C142
CU3111 Chip C. C1608JB1C104KT-N 1
C143
CU3111 Chip C. C1608JB1C104KT-N 1
C144
CU3047 Chip C. C1608JB1H103KT-N 1
C145
CU3003 Chip C. C1608CH1H020CT-AS 1
C146
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C148
CU3017 Chip C. C1608CH1H330JT-AS 1
C149
CU3017 Chip C. C1608CH1H330JT-AS 1
C150
CU3005 Chip C. C1608CH1H040CT-AS 1
C151
CU3047 Chip C. C1608JB1H103KT-N 1
C152
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C153
CU3035 Chip C. C1608JB1H102KT-AS 1
C154
CU3035 Chip C. C1608JB1H102KT-AS 1
C155
CU3007 Chip C. C1608CH1H060CT-A 1
C156
CU3047 Chip C. C1608JB1H103KT-N 1
C157
CU3035 Chip C. C1608JB1H102KT-AS 1
C158
CU3013 Chip C. C1608CH1H150JT-AS 1
C159
CU3035 Chip C. C1608JB1H102KT-AS 1
C160
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C161
CU3111 Chip C. C1608JB1C104KT-N 1
C162
CU3035 Chip C. C1608JB1H102KT-AS 1
C165
CU3111 Chip C. C1608JB1C104KT-N 1
C167
CU3047 Chip C. C1608JB1H103KT-N 1
C168
CU3111 Chip C. C1608JB1C104KT-N 1
C169
CU3027 Chip C. C1608CH1H221JT-AS 1
C171
CU3111 Chip C. C1608JB1C104KT-N 1
C172
CU3035 Chip C. C1608JB1H102KT-AS 1
Parts No. Description Parts Name Ver
Parts No. Description Parts Name Ver
Ref.
Qty
No.
DR-135 DR-235 DR-435
C173
CU3037 Chip C. C1608JB1H152KT-AS 1
C174
CU3029 Chip C. C1608JB1H331KT-AS 1
C175
CU3111 Chip C. C1608JB1C104KT-N 1
C176
CU3018 Chip C. C1608CH1H390JT-AS 1
C177
CU3018 Chip C. C1608CH1H390JT-AS 1
C179
CU3111 Chip C. C1608JB1C104KT-N 1
C180
CU3035 Chip C. C1608JB1H102KT-AS 1
C181
CU3035 Chip C. C1608JB1H102KT-AS 1
C182
CU3047 Chip C. C1608JB1H103KT-N 1
C183
CU3035 Chip C. C1608JB1H102KT-AS 1
C184
CU3035 Chip C. C1608JB1H102KT-AS 1
C185
CS0232 Chip tantalum TMCMA1V474MTR 1
C186
CU3008 Chip C. C1608CH1H070CT-A 1
C187
CU3035 Chip C. C1608JB1H102KT-AS 1
C188
CU3035 Chip C. C1608JB1H102KT-AS 1
C189
CU3011 Chip C. C1608CH1H100DT-AS 1
C190
CU3047 Chip C. C1608JB1H103KT-N 1
C191
CU3102 Chip C. C1608JB1C333KT-NS 1
C192
CU3047 Chip C. C1608JB1H103KT-N 1
C193
CU4033 Chip C. GRM42-6X7R102K500PT 1
C194
CU3012 Chip C. C1608CH1H120JT-AS 1
C195
CU3012 Chip C. C1608CH1H120JT-AS 1
C196
CU3023 Chip C. C1608CH1H101JT-AS 1
C197
CU4003 Chip C. GRM42-6CK020C500PT 1
C198
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C199
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C200
CU3035 Chip C. C1608JB1H102KT-AS 1
C201
CU4014 Chip C. GRM42-6CH180J500PT 1
C202
CU4016 Chip C. GRM42-6CH270J500PT 1
C203
CU4016 Chip C. GRM42-6CH270J500PT 1
C204
CU4013 Chip C. GRM42-6CH150J500PT 1
C205
CU3035 Chip C. C1608JB1H102KT-AS 1
C206
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C207
CU3002 Chip C. C1608CH1H010CT-AS 1
C208
CU3002 Chip C. C1608CH1H010CT-AS 1
C209
CU3035 Chip C. C1608JB1H102KT-AS 1
C210
CU3003 Chip C. C1608CH1H020CT-AS 1
C211
CU3003 Chip C. C1608CH1H020CT-AS 1
C212
CE0364 Electrolytic C. 16MV 47SWB+TS 1
C213
CU3035 Chip C. C1608JB1H102KT-AS 1
C214
CU3015 Chip C. C1608CH1H220JT-AS 1
C215
CU4016 Chip C. GRM42-6CH270J500PT 1
C216
CU4016 Chip C. GRM42-6CH270J500PT 1
C217
CU3051 Chip C. C1608JB1E223KT-NS 1
C218
CU3051 Chip C. C1608JB1E223KT-NS 1
C219
CU3035 Chip C. C1608JB1H102KT-AS 1
C220
CU3035 Chip C. C1608JB1H102KT-AS 1
C221
CU3047 Chip C. C1608JB1H103KT-N 1
C222
CU3035 Chip C. C1608JB1H102KT-AS 1
C223
CE0364 Electrolytic C. 16MV 47SWB+TS 1
C224
CU3023 Chip C. C1608CH1H101JT-AS 1
C225
CU3035 Chip C. C1608JB1H102KT-AS 1
C226
CU3035 Chip C. C1608JB1H102KT-AS 1
C227
CS0049 Chip tantalum TMCSA1C105MTR 1
C228
CU3035 Chip C. C1608JB1H102KT-AS 1
C229
CU3101 Chip C. C1608JB1C473KT-NS 1
C230
CU3035 Chip C. C1608JB1H102KT-AS 1
C231
CU3035 Chip C. C1608JB1H102KT-AS 1
C232
CU3035 Chip C. C1608JB1H102KT-AS 1
C233
CU3035 Chip C. C1608JB1H102KT-AS 1
C234
CU3035 Chip C. C1608JB1H102KT-AS 1
C235
CU3014 Chip C. C1608CH1H180JT-AS 1
C236
CU3014 Chip C. C1608CH1H180JT-AS 1
C237
CU3035 Chip C. C1608JB1H102KT-AS 1
C238
CS0049 Chip tantalum TMCSA1C105MTR 1
C239
CS0049 Chip tantalum TMCSA1C105MTR 1
C240
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C241
CU3022 Chip C. C1608CH1H820JT-AS 1
C242
CU3051 Chip C. C1608JB1E223KT-NS 1
C243
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C244
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C245
CS0049 Chip tantalum TMCSA1C105MTR 1
C246
CU3043 Chip C. C1608JB1H472KT-NS 1
C247
CU3111 Chip C. C1608JB1C104KT-N 1
C248
CU3047 Chip C. C1608JB1H103KT-N 1
C249
CU3038 Chip C. C1608JB1H182KT-AS 1
C250
CU3026 Chip C. C1608CH1H181JT-AS 1
C251
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C252
CU3035 Chip C. C1608JB1H102KT-AS 1
C253
CU3111 Chip C. C1608JB1C104KT-N 1
C254
CU3111 Chip C. C1608JB1C104KT-N 1
C255
CE0364 Electrolytic C. 16MV 47SWB+TS 1
C256
CU3111 Chip C. C1608JB1C104KT-N 1
C257
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C258
CS0049 Chip tantalum TMCSA1C105MTR 1
C259
CU3035 Chip C. C1608JB1H102KT-AS 1
C260
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C261
CU3035 Chip C. C1608JB1H102KT-AS 1
C262
CU3035 Chip C. C1608JB1H102KT-AS 1
Parts No. Description Parts Name Ver
Main Unit (DR-135)
