Alinco DR-435 - VCO Unit(DR-435); Mechanical Parts

42
Ref.
Qty
No.
DR-135 DR-235 DR-435
R259
RK3050 Chip R. MCR03EZHJ103 1
R260
RK3054 Chip R. MCR03EZHJ223 1
R261
RK3054 Chip R. MCR03EZHJ223 1
R262
RK3069 Chip R. MCR03EZHJ394 1
R263
RK3051 Chip R. MCR03EZHJ123 1
R264
RK3038 Chip R. MCR03EZHJ102 1
R265
RK3062 Chip R. MCR03EZHJ104 1
R266
RK3050 Chip R. MCR03EZHJ103 1
R268
RK3050 Chip R. MCR03EZHJ103 1
R269
RK3074 Chip R. MCR03EZHJ105 1
R271
RK4034 Chip R. ERJ12YJ471U 1
R272
RK3050 Chip R. MCR03EZHJ103 1
R273
RK3050 Chip R. MCR03EZHJ103 1
R274
RK3050 Chip R. MCR03EZHJ103 1
R277
RK3042 Chip R. MCR03EZHJ222 1
R279
RK3046 Chip R. MCR03EZHJ472 1
R280
RK1028 Chip R. ERJ8GEYJ471V 1
R281
RK3041 Chip R. MCR03EZHJ182 1
R282
RK3018 Chip R. MCR03EZHJ220 1
R283
RK3038 Chip R. MCR03EZHJ102 1
R287
RK3046 Chip R. MCR03EZHJ472 1
R291
RK3026 Chip R. MCR03EZHJ101 1
R293
RK3050 Chip R. MCR03EZHJ103 1
R295
RK3038 Chip R. MCR03EZHJ102 1
R296
RK3058 Chip R. MCR03EZHJ473 1
R297
RK3050 Chip R. MCR03EZHJ103 1
R303
RK3049 Chip R. MCR03EZHJ822 1
R304
RK3049 Chip R. MCR03EZHJ822 1
R305
RK3042 Chip R. MCR03EZHJ222 1
R306
RK3076 Chip R. MCR03EZHJ155 1
R308
RK3076 Chip R. MCR03EZHJ155 1
R309
RK3050 Chip R. MCR03EZHJ103 1
R310
RK3042 Chip R. MCR03EZHJ222 1
R315
RK3042 Chip R. MCR03EZHJ222 1
R316
RK3051 Chip R. MCR03EZHJ123 1
R318
RK3050 Chip R. MCR03EZHJ103 1
R319
RK3062 Chip R. MCR03EZHJ104 1
R320
RK3062 Chip R. MCR03EZHJ104 1
R322
RD0108 Jumper J1/6Z 1
R324
RK3014 Chip R. MCR03EZHJ100 1
R325
RK3066 Chip R. MCR03EZHJ224 1
R326
RK3038 Chip R. MCR03EZHJ102 1
R327
RK3092 Chip R. MCR03EZPFX7502 1
R328
RD3013 Resistor ERX1SJ100 1
R329
RK3062 Chip R. MCR03EZHJ104 1
R330
RK3062 Chip R. MCR03EZHJ104 1
R331
RK3038 Chip R. MCR03EZHJ102 1
R332
RK3054 Chip R. MCR03EZHJ223 1
R333
RK3062 Chip R. MCR03EZHJ104 1
R334
RK3042 Chip R. MCR03EZHJ222 1
SH101
TS0164A Case VCO CASE DR235 1
TC101
CT0012 Trimmer C. CTZ3S-10A-W1-P 1
TC102
CT0012 Trimmer C. CTZ3S-10A-W1-P 1
TC103
CT0012 Trimmer C. CTZ3S-10A-W1-P 1
TH101
XS0031 Thermistor NTCCM16084BH682KCT 1
TH102
XS0030 Thermistor NTCCM16084LH223KCT 1
RH0146 Trimmer R. MVR22HXBRN473 1
RH0148 Trimmer R. MVR22HXBRN104 1
RH0142 Trimmer R. MVR22HXBRN103 1
RH0142 Trimmer R. MVR22HXBRN103 1
RH0142 Trimmer R. MVR22HXBRN103 1
RH0146 Trimmer R. MVR22HXBRN473 1
RH0140 Trimmer R. MVR22HXBRN472 1
X101
XK0002 Discriminator CDBM455C7 1
X103
XQ0112 Xtal UM-5 21.250MHZ 1
X104
XQ0058Z Xtal UM5 30.395MHZ 1
XF101
XF0014Z Xtal Filter 30M152A 30.85MHZ 1
TZ0072 SHEET 1
UP0415 P.C.B DR435 INTEGRATED 1
SD0034 GND SPRING DR130 1
TZ0049 SILICON DUMPER 2
Ref.
Qty
No.
DR-135 DR-235 DR-435
C501
CU3047 Chip C. C1608JB1H103KT-N 1
C502
CU3023 Chip C. C1608CH1H101JT-AS 1
C503
CU3047 Chip C. C1608JB1H103KT-N 1
C504
CU3023 Chip C. C1608CH1H101JT-AS 1
C505
CU3023 Chip C. C1608CH1H101JT-AS 1
C506
CU3031 Chip C. C1608JB1H471KT-AS 1
C507
CU3035 Chip C. C1608JB1H102KT-AS 1
C508
CU3102 Chip C. C1608JB1C333KT-NS 1
C509
CS0220 Chip tantalum TMCMA1C225MTR 1
C510
CS0220 Chip tantalum TMCMA1C225MTR 1
C511
CU3006 Chip C. C1608CH1H050CT-AS 1
C512
CU3035 Chip C. C1608JB1H102KT-AS 1
Parts No. Description Parts Name Ver
Parts No. Description Parts Name Ver
VR101
VR102
VR103
VR104
VR105
VR106
VR107
VCO Unit (DR-435)
Ref.
Qty
No.
DR-135 DR-235 DR-435
C513
CS0063 Chip tantalum TMCSA1V104MTR 1
C514
CU3035 Chip C. C1608JB1H102KT-AS 1
C515
CU3003 Chip C. C1608CH1H020CT-AS 1
C516
CU3019 Chip C. C1608CH1H470JT-AS 1
C517
CU3006 Chip C. C1608CH1H050CT-AS 1
C518
CU3004 Chip C. C1608CH1H030CT-AS 1
C519
CU3002 Chip C. C1608CH1H010CT-AS 1
C520
CU3035 Chip C. C1608JB1H102KT-AS 1
C521
CU3003 Chip C. C1608CH1H020CT-AS 1
C522
CU3035 Chip C. C1608JB1H102KT-AS 1
C523
CS0372 Chip tantalum TMCMB1C106MTR 1
C524
CU3035 Chip C. C1608JB1H102KT-AS 1
C525
CU3035 Chip C. C1608JB1H102KT-AS 1
C526
CU3011 Chip C. C1608CH1H100DT-AS 1
C527
CU3011 Chip C. C1608CH1H100DT-AS 1
C528
CU3035 Chip C. C1608JB1H102KT-AS 1
C529
CU3006 Chip C. C1608CH1H050CT-AS 1
CN501
UE0368 Connector AXN39301613 1
D501
XD0131 Chip Diode 1SV214 TPH4 1
D502
XD0131 Chip Diode 1SV214 TPH4 1
D503
XD0131 Chip Diode 1SV214 TPH4 1
IC501
XA0352 IC M64076GP 1
L501
QC0101 Chip Inductor LER015TR82M 1
L503
QA0093 Chip Inductor QA0093 1
L504
QC0101 Chip Inductor LER015TR82M 1
L505
QC0096 Chip Inductor LER015TR33M 1
L506
QC0430 Chip Inductor MLF1608DR10K-T 1
L507
QC0430 Chip Inductor MLF1608DR10K-T 1
Q501
XT0124 Chip Transistor 2SC4215-Y(TE85L) 1
Q502
XE0010 Chip FET 2SK508K52 T2B 1
Q503
XT0125 Chip Transistor 2SC4245-Y(TE85L) 1
Q504
XT0125 Chip Transistor 2SC4245-Y(TE85L) 1
R501
RK3030 Chip R. MCR03EZHJ221 1
R502
RK3022 Chip R. MCR03EZHJ470 1
R503
RK3038 Chip R. MCR03EZHJ102 1
R504
RK3038 Chip R. MCR03EZHJ102 1
R505
RK3038 Chip R. MCR03EZHJ102 1
R506
RK3001 Chip R. MCR03EZHJ000 1
R507
RK3047 Chip R. MCR03EZHJ562 1
R508
RK3050 Chip R. MCR03EZHJ103 1
R509
RK3038 Chip R. MCR03EZHJ102 1
R510
RK3026 Chip R. MCR03EZHJ101 1
R511
RK3034 Chip R. MCR03EZHJ471 1
R512
RK3054 Chip R. MCR03EZHJ223 1
R513
RK3043 Chip R. MCR03EZHJ272 1
R514
RK3060 Chip R. MCR03EZHJ683 1
R515
RK3058 Chip R. MCR03EZHJ473 1
R516
RK3022 Chip R. MCR03EZHJ470 1
R517
RK3060 Chip R. MCR03EZHJ683 1
R518
RK3022 Chip R. MCR03EZHJ470 1
R519
RK3022 Chip R. MCR03EZHJ470 1
R520
RK3050 Chip R. MCR03EZHJ103 1
R521
RK3045 Chip R. MCR03EZHJ392 1
R522
RK3030 Chip R. MCR03EZHJ221 1
R523
RK3030 Chip R. MCR03EZHJ221 1
R524
RK3050 Chip R. MCR03EZHJ103 1
R525
RK3042 Chip R. MCR03EZHJ222 1
R526
RK3044 Chip R. MCR03EZHJ332 1
R527
CN7
CN6
RK3038 Chip R. MCR03EZHJ102 1
Ref.
Qty
No.
DR-135 DR-235 DR-435
UE0401 Dsub Connector K-D-09S-SE 1 1 1
UX1251 Wire WIRE DSUB 1 1 1
ES0017 Speaker 057M9017 1 1 1
UX1047 Wire Speaker 1 1 1
AA0050 Screw M2.6+6 FE/B.Zn 6 6 6
AE0029 Screw RDG-LNA-W1(01) 2 2 2
AV0006 Screw B2.6+8 Fe/Ni 16 16 16
AW0001 Screw 3+8 Fe/Ni 2 2 2
AZ0042 Washer 2 2 2
DP0127 LCD PANEL DR135 1 - -
DP0135 LCD PANEL DR235 - 1 -
DP0136 LCD PANEL DR435 - - 1
FF0015 Cloth BLIND CLOTH DR110 2 2 2
FF0017 Cloth BLIND CLOTH DR570 1 1 1
FG0273 Rubber ON AIR KEY RUBBER 1 1 1
FG0320 SP Cushion 1 1 1
KS0068 Bottom Case DR135 1 1 1 T,E
KS0070 Bottom Case G DR135 1 1 1 TG,EG
KZ0105 Front Panel DR135 1 1 1 T,E
KZ0120 Front Panel G DR135 1 1 1 TG,EG
NK0072 Knob VOL DR135 1 1 1
NK0073 Knob DIAL DR135 1 1 1
SS0093 Chassis DR135 1 1 1 T,E
SS0095 Chassis G DR135 1 1 1 TG,EG
Parts No. Description Parts Name Ver
Parts No. Description Parts Name Ver
Mechanical Parts
