Alinco DR-435 - M64076 Gp (Xa0352)

20
7) M64076GP (XA0352)
Equivalent Circuit
Dual PLL Synthesizer
Parameter Symbol Condition Min. Typ. Max. Unit
Power supply voltage Vcc
Vin=-10dBm
LPF supply voltage VF
Local oscillator input level Vin
Vcc=2.7~5.5V
Local oscillator input frequency Fin
Vcc=2.7~5.5V
Xin input level Vxin
Fxin=10~25MHz
Sine wave
Xin input frequency Fxin
Vxin=0.4~1.4Vp-p
Vcc=2.7~5.5V
Vcc=2.7~5.5V
Vin=-20~-4dBm
Fin=80~520MHz
-912V
Fin=80~520MHz
2.7 - 5.5 V
-20 - -4 dBm
80 - 520 MHz
0.4 - 1.4 Vp-p
10 - 25 MHz
