5) Tx Test Specification
TEST ITEM CONDITION ADJ STANDARD TEST STANDARD NOTE
TX Output
HI POWER
430.00MHz
440.00MHz
450.00MHz
35±1W
35±3W
35±3W
35±3W
T,TG ONLY
TX Output
MID POWER
440.00MHz 10±1W 10±2W
TX Output
LOW POWER
440.00MHz 5±1W 5±2W
Drain Current 440.00MHz Less than
9A
Less than
10A
Frequency
Deviation
440.00MHz Within ±0.5KHz Within ±1.0KHz
Spurious
440.00MHz
450.00MHz
More than 62dB
More than 62dB
More than 62dB
More than 60dB
More than 60dB
More than 60dB
450MHz T,TG ONLY
M and L standard
power is also the
same as of H power
level
WIDE
440.00MHz
3.0±0.1KHz/DEV
4.5±0.1KHz/DEV
3.0±0.2KHz/DEV
4.5±0.2KHz/DEV
MIC IN 4mVemf
MIC IN 40mVemf
Modulation
Level
NARROW
440.00MHz
2.2±0.1KHz/DEV 2.2±0.2KHz/DEV MIC IN 40mVemf
CTCSS
Modulation
Level
WIDE
440.00MHz
800±200Hz/DEV 800±200Hz/DEV 88.5Hz
3KHz LPF ON
WIDE
440.00MHz
800±200Hz/DEV 800±200Hz/DEV Code 255
3KHz LPF ON
DCS
Modulation
Level
NARROW
440.00MHz
450±100Hz/DEV 450±100Hz/DEV Code 255
3KHz LPF ON
1750Hz
Modulation
Level
WIDE
440.00MHz
3.0±0.5
KHz/DEV
3.0±0.5
KHz/DEV
DTMF
Modulation
Level
WIDE
440.00MHz
3.0±0.5
KHz/DEV
3.0±0.5
KHz/DEV
Press the V/M key
during TX
Modulation
Distortion
440.00MHz Less than 3% Less than 4%
WIDE More than 40dB More than 38dB TX S/N
NARROW More than 34dB More than 32dB
0.3~3KHz BPF
ON
430.00MHz
