Ref.No. Parts No. Description Parts Name Qty

BAT1 ED0006 Battery BR2032 1F2 1

C1 CS0408 Chip Tantal 6MCM156MATER 1

C2 CS0408 Chip Tantal 6MCM156MATER 1

C3 CU3035 Chip C. C1608JB1H102KT-AS 1

C4 CU3111 Chip C. C1608JB1C104KT-N 1

C5 CU9018 Chip C. C3216JB1C105MT-N 1

C6 CU3047 Chip C. C1608JB1H103KT-N 1

C7 CU3047 Chip C. C1608JB1H103KT-N 1

C8 CU3111 Chip C. C1608JB1C104KT-N 1

C9 CU3051 Chip C. C1608JB1E223KT-NS 1

C10 CU3111 Chip C. C1608JB1C104KT-N 1

C11 CU3111 Chip C. C1608JB1C104KT-N 1

C12 CU9018 Chip C. C3216JB1C105MT-N 1

C13 CU3051 Chip C. C1608JB1E223KT-NS 1

C14 CU3116 Chip C. C1608CH1H471JT-AS 1

C15 CU3051 Chip C. C1608JB1E223KT-NS 1

C16 CU3051 Chip C. C1608JB1E223KT-NS 1

C17 CU3045 Chip C. C1608JB1H682KT-NS 1

C18 CU3045 Chip C. C1608JB1H682KT-NS 1

C19 CU3047 Chip C. C1608JB1H103KT-N 1

C20 CU9018 Chip C. C3216JB1C105MT-N 1

C21 CU3111 Chip C. C1608JB1C104KT-N 1

C22 CU3035 Chip C. C1608JB1H102KT-AS 1

C23 CU3111 Chip C. C1608JB1C104KT-N 1

C24 CU3004 Chip C. C1608CH1H030CT-AS 1

C25 CU3047 Chip C. C1608JB1H103KT-N 1

C26 CU3027 Chip C. C1608CH1H221JT-AS 1

C27 CU3023 Chip C. C1608CH1H101JT-AS 1

C28 CU3111 Chip C. C1608JB1C104KT-N 1

C29 CU3111 Chip C. C1608JB1C104KT-N 1

C30 CU3111 Chip C. C1608JB1C104KT-N 1

C31 CU3062 Chip C. C1608CH1H160JT-A 1

C32 CU3111 Chip C. C1608JB1C104KT-N 1

C33 CS0049 Chip Tantal TMCSA1C105MTR 1

C34 CS0394 Chip Tantal TMCMB0J476MTR 1

C35 CU3111 Chip C. C1608JB1C104KT-N 1

C36 CU3019 Chip C. C1608CH1H470JT-AS 1

C37 CU3043 Chip C. C1608JB1H472KT-NS 1

C38 CU3111 Chip C. C1608JB1C104KT-N 1

C39 CU3047 Chip C. C1608JB1H103KT-N 1

C40 CU3045 Chip C. C1608JB1H682KT-NS 1

C41 CU3116 Chip C. C1608CH1H471JT-AS 1

C42 CU9018 Chip C. C3216JB1C105MT-N 1

C43 CU3039 Chip C. C1608JB1H222KT-AS 1

C44 CU3051 Chip C. C1608JB1E223KT-NS 1

C45 CU3045 Chip C. C1608JB1H682KT-NS 1

C46 CU3039 Chip C. C1608JB1H222KT-AS 1

C48 CU3111 Chip C. C1608JB1C104KT-N 1

CN1 UE0402 Connector PI28B11M 1

D1 XL0036 LED SML-310MTT86 1

D2 XL0035 LED SML-310UTT86 1

D3 XL0036 LED SML-310MTT86 1

D4 XL0036 LED SML-310MTT86 1

D5 XD0291 Diode MA729-TX 1

D6 XD0291 Diode MA729-TX 1

IC1 XA0678 IC TGT0210Q 1

IC2 XA0463 IC TA75S393F(TE85L) 1

IC3 XA0679 IC TMT0110Q 1

IC4 XA0224 IC NJM2904M T1 1

IC5 XA0326 IC NJM2903(T1) 1

IC6 XA0680 IC ADM232AARN-REEL 1

IC7 XA0668 IC S-80829ALNP-EAS-T2 1

L2 QB0044 Chip Coil BK1608HM601-T 1

Q1 XT0095 Transister 2SC4081 T106R 1

Q2 XT0094 Transister 2SA1576A T106R 1

Q3 XT0094 Transister 2SA1576A T106R 1

Q4 XT0094 Transister 2SA1576A T106R 1

Q5 XE0029 FET 2SK1580-T1 1

Q6 XT0095 Transister 2SC4081 T106R 1

Q7 XU0078 Transister UN521L-TX 1

Q8 XT0095 Transister 2SC4081 T106R 1

Q9 XT0094 Transister 2SA1576A T106R 1

Q10 XT0095 Transister 2SC4081 T106R 1

Q11 XT0095 Transister 2SC4081 T106R 1

R1 RK3062 Chip R. MCR03EZHJ104 1

R2 RK3062 Chip R. MCR03EZHJ104 1

R3 RK3062 Chip R. MCR03EZHJ104 1

R4 RK3062 Chip R. MCR03EZHJ104 1

R5 RK3034 Chip R. MCR03EZHJ471 1

R6 RK3034 Chip R. MCR03EZHJ471 1

R7 RK3034 Chip R. MCR03EZHJ471 1

R8 RK3032 Chip R. MCR03EZHJ331 1

R9 RK3038 Chip R. MCR03EZHJ102 1

R10 RK3050 Chip R. MCR03EZHJ103 1

R11 RK3066 Chip R. MCR03EZHJ224 1

R12 RK3038 Chip R. MCR03EZHJ102 1

Ref.No. Parts No. Description Parts Name Qty

R13 RK3038 Chip R. MCR03EZHJ102 1

R14 RK3038 Chip R. MCR03EZHJ102 1

R15 RK3038 Chip R. MCR03EZHJ102 1

R16 RK3038 Chip R. MCR03EZHJ102 1

R17 RK3050 Chip R. MCR03EZHJ103 1

R18 RK3050 Chip R. MCR03EZHJ103 1

R19 RK3038 Chip R. MCR03EZHJ102 1

R20 RK3038 Chip R. MCR03EZHJ102 1

R21 RK3053 Chip R. MCR03EZHJ183 1

R22 RK3054 Chip R. MCR03EZHJ223 1

R23 RK3050 Chip R. MCR03EZHJ103 1

R24 RK3071 Chip R. MCR03EZHJ564 1

R25 RK3050 Chip R. MCR03EZHJ103 1

R26 RK3050 Chip R. MCR03EZHJ103 1

R27 RK3050 Chip R. MCR03EZHJ103 1

R28 RK3048 Chip R. MCR03EZHJ682 1

R29 RK3050 Chip R. MCR03EZHJ103 1

R30 RK3044 Chip R. MCR03EZHJ332 1

R32 RK3042 Chip R. MCR03EZHJ222 1

R33 RK3050 Chip R. MCR03EZHJ103 1

R34 RK3051 Chip R. MCR03EZHJ123 1

R35 RK3051 Chip R. MCR03EZHJ123 1

R36 RK3054 Chip R. MCR03EZHJ223 1

R37 RK3051 Chip R. MCR03EZHJ123 1

R38 RK3051 Chip R. MCR03EZHJ123 1

R39 RK3050 Chip R. MCR03EZHJ103 1

R40 RK3051 Chip R. MCR03EZHJ123 1

R41 RK3054 Chip R. MCR03EZHJ223 1

R42 RK3044 Chip R. MCR03EZHJ332 1

R44 RK3001 Chip R. MCR03EZHJ000 1

R45 RK3030 Chip R. MCR03EZHJ221 1

R46 RK3057 Chip R. MCR03EZHJ393 1

R47 RK3050 Chip R. MCR03EZHJ103 1

R48 RK3050 Chip R. MCR03EZHJ103 1

R49 RK3046 Chip R. MCR03EZHJ472 1

R50 RK3038 Chip R. MCR03EZHJ102 1

R51 RK3061 Chip R. MCR03EZHJ823 1

R52 RK3058 Chip R. MCR03EZHJ473 1

R53 RK3054 Chip R. MCR03EZHJ223 1

R54 RK3001 Chip R. MCR03EZHJ000 1

R55 RK3062 Chip R. MCR03EZHJ104 1

R56 RK3064 Chip R. MCR03EZHJ154 1

R57 RK3058 Chip R. MCR03EZHJ473 1

R58 RK3050 Chip R. MCR03EZHJ103 1

R59 RK3001 Chip R. MCR03EZHJ000 1

R60 RK3044 Chip R. MCR03EZHJ332 1

R61 RK3001 Chip R. MCR03EZHJ000 1

R62 RK3060 Chip R. MCR03EZHJ683 1

R63 RK3029 Chip R. MCR03EZHJ181 1

R64 RK3050 Chip R. MCR03EZHJ103 1

R65 RK3050 Chip R. MCR03EZHJ103 1

R66 RK3059 Chip R. MCR03EZHJ563 1

R67 RK3050 Chip R. MCR03EZHJ103 1

R68 RK3054 Chip R. MCR03EZHJ223 1

R69 RK3050 Chip R. MCR03EZHJ103 1

R70 RK3050 Chip R. MCR03EZHJ103 1

R71 RK3050 Chip R. MCR03EZHJ103 1

R72 RK3050 Chip R. MCR03EZHJ103 1

R73 RK3001 Chip R. MCR03EZHJ000 1

R74 RK3058 Chip R. MCR03EZHJ473 1

R75 RK3062 Chip R. MCR03EZHJ104 1

R76 RK3064 Chip R. MCR03EZHJ154 1

R77 RK3030 Chip R. MCR03EZHJ221 1

R78 RK3050 Chip R. MCR03EZHJ103 1

R79 RK3050 Chip R. MCR03EZHJ103 1

R80 RK3058 Chip R. MCR03EZHJ473 1

R81 RK3058 Chip R. MCR03EZHJ473 1

R82 RK3044 Chip R. MCR03EZHJ332 1

R83 RK3074 Chip R. MCR03EZHJ105 1

R84 RK3050 Chip R. MCR03EZHJ103 1

R85 RK3046 Chip R. MCR03EZHJ472 1

R87 RK3062 Chip R. MCR03EZHJ104 1

R88 RK3062 Chip R. MCR03EZHJ104 1

VR1 RH0142 Trim.Pot MVR22HXBRN103 1

VR2 RH0142 Trim.Pot MVR22HXBRN103 1

W2 UX1253 Connector WIRE TNC 1

X1 XQ0124 Xtal AT-49 7.9872MHZ 1

UP0402 PCB EJ41U (TNC ) 0.125

FF0033 VELCRO A 1

FG0040 Cushion 2

TZ0024 Insulator LITHIUM BATT. 1

TZ0056 Insulator SILICON 49U 1

YZ0131 Tape #9110 12X1mm 25

TNC (EJ41U)
