Alinco DR-435 - VCO Unit(DR-235); Main Unit(DR-435)

39
Ref.
Qty
No.
DR-135 DR-235 DR-435
R295
RK3038 Chip R. MCR03EZHJ102 1
R297
RK3050 Chip R. MCR03EZHJ103 1
R303
RK3057 Chip R. MCR03EZHJ393 1
R304
RK3057 Chip R. MCR03EZHJ393 1
R306
RK3076 Chip R. MCR03EZHJ155 1
R308
RK3076 Chip R. MCR03EZHJ155 1
R309
RK3050 Chip R. MCR03EZHJ103 1
R311
RK3038 Chip R. MCR03EZHJ102 1
R312
RK3038 Chip R. MCR03EZHJ102 1
R313
RK3038 Chip R. MCR03EZHJ102 1
R315
RK3042 Chip R. MCR03EZHJ222 1
R316
RK3051 Chip R. MCR03EZHJ123 1
R318
RK3050 Chip R. MCR03EZHJ103 1
R319
RK3062 Chip R. MCR03EZHJ104 1
R320
RK3062 Chip R. MCR03EZHJ104 1
R322
RD0108 Jumper J1/6Z 1
R323
RK3001 Chip R. MCR03EZHJ000 1
R324
RK3014 Chip R. MCR03EZHJ100 1
R325
RK3066 Chip R. MCR03EZHJ224 1
R326
RK3038 Chip R. MCR03EZHJ102 1
R327
RK3092 Chip R. MCR03EZPFX7502 1
R328
RD3013 Resistor ERX1SJ100 1
R329
RK3062 Chip R. MCR03EZHJ104 1
R330
RK3062 Chip R. MCR03EZHJ104 1
R331
RK3040 Chip R. MCR03EZHJ152 1
R332
RK3054 Chip R. MCR03EZHJ223 1
R333
RK3062 Chip R. MCR03EZHJ104 1
R334
RK3042 Chip R. MCR03EZHJ222 1
TC101
CT0012 Trimmer CTZ3S-10A-W1-P 1
TH101
XS0031 Thermistor NTCCM16084BH682KCT 1
RH0146 Trimmer R. MVR22HXBRN473 1
RH0148 Trimmer R. MVR22HXBRN104 1
RH0142 Trimmer R. MVR22HXBRN103 1
RH0144 Trimmer R. MVR22HXBRN223 1
RH0142 Trimmer R. MVR22HXBRN103 1
RH0146 Trimmer R. MVR22HXBRN473 1
RH0140 Trimmer R. MVR22HXBRN472 1
RH0148 Trimmer R. MVR22HXBRN104 1
W101
W102
X101
XK0002 Discriminator CDBM455C7 1
X103
XQ0096 Xtal 12.8MHZ 5PPM UM5 1
X104
XQ0058A Xtal UM-5 30.395MHZ 1
XF101
XF0014Z Xtal Filter 30M152A 30.85MHZ 1
SD0034 GND SPRING DR130 1
TS0164A VCO CASE DR235 1
TZ0049 SILICON DUMPER 1
TZ0072 SHEET 1
UP0414 P.C.Board 1
Ref.
Qty
No.
DR-135 DR-235 DR-435
C503
CU3039 Chip C. C1608JB1H222KT-AS 1
C504
CU3051 Chip C. C1608JB1E223KT-NS 1
C505
CS0220 Chip tantalum TMCMA1C225MTR 1
C506
CS0220 Chip tantalum TMCMA1C225MTR 1
C507
CU3035 Chip C. C1608JB1H102KT-AS 1
C508
CS0063 Chip tantalum TMCSA1V104MTR 1
C511
CU3047 Chip C. C1608JB1H103KT-N 1
C512
CU3047 Chip C. C1608JB1H103KT-N 1
C513
CU3008 Chip C. C1608CH1H070CT-A 1
C514
CU3035 Chip C. C1608JB1H102KT-AS 1
C515
CU3006 Chip C. C1608CH1H050CT-AS 1
C516
CU3035 Chip C. C1608JB1H102KT-AS 1
C517
CU3035 Chip C. C1608JB1H102KT-AS 1
C518
CU3003 Chip C. C1608CH1H020CT-AS 1
C519
CU3035 Chip C. C1608JB1H102KT-AS 1
C520
CS0382 Chip tantalum TMCMB1A226MTR 1
C523
CU3004 Chip C. C1608CH1H030CT-AS 1
C524
CU3027 Chip C. C1608CH1H221JT-AS 1
C525
CU3009 Chip C. C1608CH1H080CT-A 1
C526
CU3002 Chip C. C1608CH1H010CT-AS 1
C527
CU3009 Chip C. C1608CH1H080CT-A 1
C528
CU3003 Chip C. C1608CH1H020CT-AS 1
C529
CU3035 Chip C. C1608JB1H102KT-AS 1
C530
CU3035 Chip C. C1608JB1H102KT-AS 1
C531
CU3011 Chip C. C1608CH1H100DT-AS 1
CN501
UE0420 Connector B8P-BC-2 1
CN50
2
UE0185 Connector B6P-BC-2 1
D501
XD0131 Chip Diode 1SV214 TPH4 1
D503
XD0300 Chip Diode 1SV262TPH2 1
D504
XD0300 Chip Diode 1SV262TPH2 1
IC501
XA0352 IC M64076GP 1
L501
QC0104 Chip Inductor LER015T1R5M 1
L503
QA0147 Chip Inductor 4VP-5.25T 1
L504
QC0104 Chip Inductor LER015T1R5M 1
Parts No. Description Parts Name Ver
Parts No. Description Parts Name Ver
VR101
VR102
VR103
VR104
VR105
VR106
VR107
VR108
Wire #22BH1-020-H1 1
Wire #30BH1-020-H1 1
MBAG02GG
MBCL02GG
VCO Unit (DR-235)
Ref.
Qty
No.
DR-135 DR-235 DR-435
L505
QC0104 Chip Inductor LER015T1R5M 1
L506
QC0544 Chip Inductor LER015TR47M 1
L507
QC0430 Chip Inductor MLF1608DR10K-T 1
Q501
XT0124 Chip Transistor 2SC4215-Y(TE85L) 1
Q503
XE0010 FET 2SK508K52 T2B 1
Q504
XT0124 Chip Transistor 2SC4215-Y(TE85L) 1
R502
RK3022 Chip R. MCR03EZHJ470 1
R503
RK3030 Chip R. MCR03EZHJ221 1
R504
RK3001 Chip R. MCR03EZHJ000 1
R505
RK3048 Chip R. MCR03EZHJ682 1
R506
RK3052 Chip R. MCR03EZHJ153 1
R507
RK3042 Chip R. MCR03EZHJ222 1
R508
RK3026 Chip R. MCR03EZHJ101 1
R509
RK3034 Chip R. MCR03EZHJ471 1
R510
RK3054 Chip R. MCR03EZHJ223 1
R511
RK3044 Chip R. MCR03EZHJ332 1
R512
RK3022 Chip R. MCR03EZHJ470 1
R513
RK3050 Chip R. MCR03EZHJ103 1
R514
RK3060 Chip R. MCR03EZHJ683 1
R518
RK3025 Chip R. MCR03EZHJ820 1
R519
RK3022 Chip R. MCR03EZHJ470 1
R520
RK3045 Chip R. MCR03EZHJ392 1
R521
RK3026 Chip R. MCR03EZHJ101 1
R522
RK3034 Chip R. MCR03EZHJ471 1
R523
RK3050 Chip R. MCR03EZHJ103 1
Ref.
Qty
No.
DR-135 DR-235 DR-435
C101
CU3047 Chip C. C1608JB1H103KT-N 1
C102
CU3047 Chip C. C1608JB1H103KT-N 1
C103
CS0049 Chip tantalum TMCSA1C105MTR 1
C104
CU3047 Chip C. C1608JB1H103KT-N 1
C105
CS0394 Chip tantalum TMCMB0J476MTR 1
C106
CU3051 Chip C. C1608JB1E223KT-NS 1
C107
CU3111 Chip C. C1608JB1C104KT-N 1
C108
CU3047 Chip C. C1608JB1H103KT-N 1
C109
CS0372 Chip tantalum TMCMB1C106MTR 1
C110
CU3035 Chip C. C1608JB1H102KT-AS 1
C111
CU3047 Chip C. C1608JB1H103KT-N 1
C112
CU3047 Chip C. C1608JB1H103KT-N 1
C113
CU3047 Chip C. C1608JB1H103KT-N 1
C114
CU3035 Chip C. C1608JB1H102KT-AS 1
C115
CE0350 Electrolytic C. 16MV 100HC 1
C116
CU3047 Chip C. C1608JB1H103KT-N 1
C117
CU3035 Chip C. C1608JB1H102KT-AS 1
C118
CU3049 Chip C. C1608JB1E153KT-NS 1
C119
CU3051 Chip C. C1608JB1E223KT-NS 1
C120
CU3020 Chip C. C1608CH1H560JT-AS 1
C121
CU3035 Chip C. C1608JB1H102KT-AS 1
C122
CU3047 Chip C. C1608JB1H103KT-N 1
C123
CU3012 Chip C. C1608CH1H120JT-AS 1
C124
CU3040 Chip C. C1608JB1H272KT-NS 1
C125
CU3044 Chip C. C1608JB1H562KT-NS 1
C126
CU3038 Chip C. C1608JB1H182KT-AS 1
C127
CU3041 Chip C. C1608JB1H332KT-NS 1
C129
CU3008 Chip C. C1608CH1H070CT-A 1
C130
CS0220 Chip tantalum TMCMA1C225MTR 1
C131
CU3035 Chip C. C1608JB1H102KT-AS 1
C132
CU3035 Chip C. C1608JB1H102KT-AS 1
C133
CU3027 Chip C. C1608CH1H221JT-AS 1
C134
CU3042 Chip C. C1608JB1H392KT-NS 1
C135
CU3044 Chip C. C1608JB1H562KT-NS 1
C137
CU3017 Chip C. C1608CH1H330JT-AS 1
C138
CS0049 Chip tantalum TMCSA1C105MTR 1
C139
CU3031 Chip C. C1608JB1H471KT-AS 1
C141
CU3008 Chip C. C1608CH1H070CT-A 1
C142
CU3111 Chip C. C1608JB1C104KT-N 1
C143
CU3111 Chip C. C1608JB1C104KT-N 1
C144
CU3015 Chip C. C1608CH1H220JT-AS 1
C145
CU3064 Chip C. C1608CH1H1R5CT-AS 1
C146
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C149
CU3035 Chip C. C1608JB1H102KT-AS 1
C150
CU3016 Chip C. C1608CH1H270JT-AS 1
C151
CU3035 Chip C. C1608JB1H102KT-AS 1
C152
CE0339 Electrolytic C. 16MV 10SWB+TS 1
C153
CU3003 Chip C. C1608CH1H020CT-AS 1
C154
CU3035 Chip C. C1608JB1H102KT-AS 1
C155
CU3011 Chip C. C1608CH1H100DT-AS 1
C156
CU3047 Chip C. C1608JB1H103KT-N 1
C157
CU3035 Chip C. C1608JB1H102KT-AS 1
C158
CU3004 Chip C. C1608CH1H030CT-AS 1
C159
CU3018 Chip C. C1608CH1H390JT-AS 1
C160
CU3016 Chip C. C1608CH1H270JT-AS 1
C161
CU3035 Chip C. C1608JB1H102KT-AS 1
C162
CU3023 Chip C. C1608CH1H101JT-AS 1
C165
CU3111 Chip C. C1608JB1C104KT-N 1
Parts No. Description Parts Name Ver
Parts No. Description Parts Name Ver
Main Unit (DR-435)
