Figure 10-3：LPC FMC3 Connector Diagram
The 1
st
FMC LPC Connectors Pin Assignment
Signal Name
FPGA Pin Number
FPGA Pin
Name
Description
FMC1_LPC_CLK0_P
IO_L11P_T1U_N8_GC_47
Y23
FMC Reference 1
st
Reference Clock P
FMC1_LPC_CLK0_N
IO_L11N_T1U_N9_GC_47
AA23
FMC Reference 1
st
Reference Clock N
FMC1_LPC_CLK1_P
IO_L11P_T1U_N8_GC_48
AD30
FMC Reference 2
nd
Reference Clock P
FMC1_LPC_CLK1_N
IO_L11N_T1U_N9_GC_48
AD31
FMC Reference 2
nd
Reference Clock N
FMC1_LPC_LA00_CC_P
IO_L12P_T1U_N10_GC_47
AA24
FMC Reference 0
th
Data
( Clock ) P
FMC1_LPC_LA00_CC_N
IO_L12N_T1U_N11_GC_47
AA25
FMC Reference 0
th
Data
