KINTEX UltraScale+ FPGA Board AXKU040 User Manual
30 / 59
www.alinx.com
( Clock ) N
FMC1_LPC_LA01_CC_P
IO_L13P_T2L_N0_GC_QBC_47
W23
FMC Reference 1
st
Data
( Clock ) P
FMC1_LPC_LA01_CC_N
IO_L13N_T2L_N1_GC_QBC_47
W24
FMC Reference 1
st
Data
( Clock ) N
FMC1_LPC_LA02_P
IO_L10P_T1U_N6_QBC_AD4P_47
AB21
FMC Reference 2
nd
Data
P
FMC1_LPC_LA02_N
IO_L10N_T1U_N7_QBC_AD4N_47
AC21
FMC Reference 2
nd
Data
N
FMC1_LPC_LA03_P
IO_L8P_T1L_N2_AD5P_47
AC22
FMC Reference 3
rd
Data
P
FMC1_LPC_LA03_N
IO_L8N_T1L_N3_AD5N_47
AC23
FMC Reference 3
rd
Data
N
FMC1_LPC_LA04_P
IO_L7P_T1L_N0_QBC_AD13P_47
AA22
FMC Reference 4
th
Data
P
FMC1_LPC_LA04_N
IO_L7N_T1L_N1_QBC_AD13N_47
AB22
FMC Reference 4
th
Data
N
FMC1_LPC_LA05_P
IO_L2P_T0L_N2_47
AD25
FMC Reference 5
th
Data
P
FMC1_LPC_LA05_N
IO_L2N_T0L_N3_47
AD26
FMC Reference 5
th
Data
N
FMC1_LPC_LA06_P
IO_L3P_T0L_N4_AD15P_47
AB24
FMC Reference 6
th
Data
P
FMC1_LPC_LA06_N
IO_L3N_T0L_N5_AD15N_47
AC24
FMC Reference 6
th
Data
N
FMC1_LPC_LA07_P
IO_L6P_T0U_N10_AD6P_47
AB25
FMC Reference 7
th
Data
P
FMC1_LPC_LA07_N
IO_L6N_T0U_N11_AD6N_47
AB26
FMC Reference 7
th
Data
N
FMC1_LPC_LA08_P
IO_L4P_T0U_N6_DBC_AD7P_47
AC26
FMC Reference 8
th
Data
P
FMC1_LPC_LA08_N
IO_L4N_T0U_N7_DBC_AD7N_47
AC27
FMC Reference 8
th
Data
N
FMC1_LPC_LA09_P
IO_L1P_T0L_N0_DBC_47
Y26
FMC Reference 9
th
Data
P
FMC1_LPC_LA09_N
IO_L1N_T0L_N1_DBC_47
Y27
FMC Reference 9
th
Data
N
