FMC1_LPC_LA10_P
IO_L5P_T0U_N8_AD14P_47
AA27
FMC Reference 10
th
Data P
FMC1_LPC_LA10_N
IO_L5N_T0U_N9_AD14N_47
AB27
FMC Reference 10
th
Data N
FMC1_LPC_LA11_P
IO_L18P_T2U_N10_AD2P_47
V21
FMC Reference 11
th
Data P
FMC1_LPC_LA11_N
IO_L18N_T2U_N11_AD2N_47
W21
FMC Reference 11
th
Data N
FMC1_LPC_LA12_P
IO_L9P_T1L_N4_AD12P_47
AA20
FMC Reference 12
th
Data P
FMC1_LPC_LA12_N
IO_L9N_T1L_N5_AD12N_47
AB20
FMC Reference 12
th
Data N
FMC1_LPC_LA13_P
IO_L14P_T2L_N2_GC_47
W25
FMC Reference 13
th
Data P
FMC1_LPC_LA13_N
IO_L14N_T2L_N3_GC_47
Y25
FMC Reference 13
th
Data N
FMC1_LPC_LA14_P
IO_L16P_T2U_N6_QBC_AD3P_47
V22
FMC Reference 14
th
Data P
FMC1_LPC_LA14_N
IO_L16N_T2U_N7_QBC_AD3N_47
V23
FMC Reference 14
th
Data N
FMC1_LPC_LA15_P
IO_L17P_T2U_N8_AD10P_47
T22
FMC Reference 15
th
Data P
FMC1_LPC_LA15_N
IO_L17N_T2U_N9_AD10N_47
T23
FMC Reference 15
th
Data N
FMC1_LPC_LA16_P
IO_L15P_T2L_N4_AD11P_47
U21
FMC Reference 16
th
Data P
FMC1_LPC_LA16_N
IO_L15N_T2L_N5_AD11N_47
U22
FMC Reference 16
th
Data N
FMC1_LPC_LA17_CC_P
IO_L12P_T1U_N10_GC_48
AC31
FMC Reference 17
th
Data ( Clock ) P
FMC1_LPC_LA17_CC_N
IO_L12N_T1U_N11_GC_48
AC32
FMC Reference 17
th
Data ( Clock ) N
FMC1_LPC_LA18_CC_P
IO_L13P_T2L_N0_GC_QBC_48
AA32
FMC Reference 18
th
Data ( Clock ) P
FMC1_LPC_LA18_CC_N
IO_L13N_T2L_N1_GC_QBC_48
AB32
FMC Reference 18
th
Data ( Clock ) N
FMC1_LPC_LA19_P
IO_L7P_T1L_N0_QBC_AD13P_48
AG31
FMC Reference 19
th
