Data P
FMC1_LPC_LA19_N
IO_L7N_T1L_N1_QBC_AD13N_48
AG32
FMC Reference 19
th
Data N
FMC1_LPC_LA20_P
IO_L6P_T0U_N10_AD6P_48
AF30
FMC Reference 20
th
Data P
FMC1_LPC_LA20_N
IO_L6N_T0U_N11_AD6N_48
AG30
FMC Reference 20
th
Data N
FMC1_LPC_LA21_P
IO_L10P_T1U_N6_QBC_AD4P_48
AE33
FMC Reference 21
st
Data P
FMC1_LPC_LA21_N
IO_L10N_T1U_N7_QBC_AD4N_48
AF34
FMC Reference 21
st
Data N
FMC1_LPC_LA22_P
IO_L8P_T1L_N2_AD5P_48
AF33
FMC Reference 22
nd
Data P
FMC1_LPC_LA22_N
IO_L8N_T1L_N3_AD5N_48
AG34
FMC Reference 22
nd
Data N
FMC1_LPC_LA23_P
IO_L4P_T0U_N6_DBC_AD7P_48
AF29
FMC Reference 23
rd
Data P
FMC1_LPC_LA23_N
IO_L4N_T0U_N7_DBC_AD7N_48
AG29
FMC Reference 23
rd
Data N
FMC1_LPC_LA24_P
IO_L15P_T2L_N4_AD11P_48
AC34
FMC Reference 24
th
Data P
FMC1_LPC_LA24_N
IO_L15N_T2L_N5_AD11N_48
AD34
FMC Reference 24
th
Data N
FMC1_LPC_LA25_P
IO_L9P_T1L_N4_AD12P_48
AE32
FMC Reference 25
th
Data P
FMC1_LPC_LA25_N
IO_L9N_T1L_N5_AD12N_48
AF32
FMC Reference 25
th
Data N
FMC1_LPC_LA26_P
IO_L16P_T2U_N6_QBC_AD3P_48
AA29
FMC Reference 26
th
Data P
FMC1_LPC_LA26_N
IO_L16N_T2U_N7_QBC_AD3N_48
AB29
FMC Reference 26
th
Data N
FMC1_LPC_LA27_P
IO_L14P_T2L_N2_GC_48
AB30
FMC Reference 27
th
Data P
FMC1_LPC_LA27_N
IO_L14N_T2L_N3_GC_48
AB31
FMC Reference 27
th
Data N
FMC1_LPC_LA28_P
IO_L17P_T2U_N8_AD10P_48
AA34
FMC Reference 28
th
Data P
