FMC1_LPC_LA28_N
IO_L17N_T2U_N9_AD10N_48
AB34
FMC Reference 28
th
Data N
FMC1_LPC_LA29_P
IO_L18P_T2U_N10_AD2P_48
AC33
FMC Reference 29
th
Data P
FMC1_LPC_LA29_N
IO_L18N_T2U_N11_AD2N_48
AD33
FMC Reference 29
th
Data N
FMC1_LPC_LA30_P
IO_L2P_T0L_N2_48
AE28
FMC Reference 30
th
Data P
FMC1_LPC_LA30_N
IO_L2N_T0L_N3_48
AF28
FMC Reference 30
th
Data N
FMC1_LPC_LA31_P
IO_L5P_T0U_N8_AD14P_48
AD29
FMC Reference 31
st
Data P
FMC1_LPC_LA31_N
IO_L5N_T0U_N9_AD14N_48
AE30
FMC Reference 31
st
Data N
FMC1_LPC_LA32_P
IO_L1P_T0L_N0_DBC_48
AE27
FMC Reference 32
nd
Data P
FMC1_LPC_LA32_N
IO_L1N_T0L_N1_DBC_48
AF27
FMC Reference 32
nd
Data N
FMC1_LPC_LA33_P
IO_L3P_T0L_N4_AD15P_48
AC28
FMC Reference 33
rd
Data P
FMC1_LPC_LA33_N
IO_L3N_T0L_N5_AD15N_48
AD28
FMC Reference 33
rd
Data N
FMC1_LPC_SCL
IO_T2U_N12_47
Y21
FMC I2C Bus Clock
FMC1_LPC_SDA
IO_T3U_N12_47
U29
FMC I2C Bus Data
The 2
nd
FMC LPC Connectors Pin Assignment
Signal Name
FPGA Pin Number
FPGA Pin
Name
Description
FMC2_LPC_CLK0_P
IO_L11P_T1U_N8_GC_64
AG12
FMC Reference 1
st
Reference Clock P
FMC2_LPC_CLK0_N
IO_L11N_T1U_N9_GC_64
AH12
FMC Reference 1
st
Reference Clock N
FMC2_LPC_CLK1_P
IO_L13P_T2L_N0_GC_
QBC_A06_D22_65
P26
FMC Reference 2
nd
Reference Clock P
FMC2_LPC_CLK1_N
IO_L13N_T2L_N1_GC_
QBC_A07_D23_65
N26
FMC Reference 2
nd
Reference Clock N
