Alinx AXKU040 - Page 34

KINTEX UltraScale+ FPGA Board AXKU040 User Manual
34 / 59
www.alinx.com
FMC2_LPC_LA00_CC_P
IO_L12P_T1U_N10_GC_64
AG11
FMC Reference 0
th
Data
( Clock ) P
FMC2_LPC_LA00_CC_N
IO_L12N_T1U_N11_GC_64
AH11
FMC Reference 0
th
Data
( Clock ) N
FMC2_LPC_LA01_CC_P
IO_L13P_T2L_N0_GC_QBC_64
AF10
FMC Reference 1
st
Data
( Clock ) P
FMC2_LPC_LA01_CC_N
IO_L13N_T2L_N1_GC_QBC_64
AG10
FMC Reference 1
st
Data
( Clock ) N
FMC2_LPC_LA02_P
IO_L2P_T0L_N2_64
AN13
FMC Reference 2
nd
Data
P
FMC2_LPC_LA02_N
IO_L2N_T0L_N3_64
AP13
FMC Reference 2
nd
Data
N
FMC2_LPC_LA03_P
IO_L6P_T0U_N10_AD6P_64
AK13
FMC Reference 3
rd
Data
P
FMC2_LPC_LA03_N
IO_L6N_T0U_N11_AD6N_64
AL13
FMC Reference 3
rd
Data
N
FMC2_LPC_LA04_P
IO_L10P_T1U_N6_QBC_AD4P_64
AD11
FMC Reference 4
th
Data
P
FMC2_LPC_LA04_N
IO_L10N_T1U_N7_QBC_AD4N_64
AE11
FMC Reference 4
th
Data
N
FMC2_LPC_LA05_P
IO_L4P_T0U_N6_DBC_AD7P_64
AM12
FMC Reference 5
th
Data
P
FMC2_LPC_LA05_N
IO_L4N_T0U_N7_DBC_AD7N_64
AN12
FMC Reference 5
th
Data
N
FMC2_LPC_LA06_P
IO_L8P_T1L_N2_AD5P_64
AH13
FMC Reference 6
th
Data
P
FMC2_LPC_LA06_N
IO_L8N_T1L_N3_AD5N_64
AJ13
FMC Reference 6
th
Data
N
FMC2_LPC_LA07_P
IO_L14P_T2L_N2_GC_64
AF9
FMC Reference 7
th
Data
P
FMC2_LPC_LA07_N
IO_L14N_T2L_N3_GC_64
AG9
FMC Reference 7
th
Data
N
FMC2_LPC_LA08_P
IO_L16P_T2U_N6_QBC_AD3P_64
AD10
FMC Reference 8
th
Data
P
FMC2_LPC_LA08_N
IO_L16N_T2U_N7_QBC_AD3N_64
AE10
FMC Reference 8
th
Data
N
FMC2_LPC_LA09_P
IO_L9P_T1L_N4_AD12P_64
AE12
FMC Reference 9
th
Data
