P
FMC2_LPC_LA09_N
IO_L9N_T1L_N5_AD12N_64
AF12
FMC Reference 9
th
Data
N
FMC2_LPC_LA10_P
IO_L5P_T0U_N8_AD14P_64
AK12
FMC Reference 10
th
Data
P
FMC2_LPC_LA10_N
IO_L5N_T0U_N9_AD14N_64
AL12
FMC Reference 10
th
Data
N
FMC2_LPC_LA11_P
IO_L17P_T2U_N8_AD10P_64
AD9
FMC Reference 11
th
Data
P
FMC2_LPC_LA11_N
IO_L17N_T2U_N9_AD10N_64
AD8
FMC Reference 11
th
Data
N
FMC2_LPC_LA12_P
IO_L7P_T1L_N0_QBC_AD13P_64
AE13
FMC Reference 12
th
Data
P
FMC2_LPC_LA12_N
IO_L7N_T1L_N1_QBC_AD13N_64
AF13
FMC Reference 12
th
Data
N
FMC2_LPC_LA13_P
IO_L1P_T0L_N0_DBC_64
AP11
FMC Reference 13
th
Data
P
FMC2_LPC_LA13_N
IO_L1N_T0L_N1_DBC_64
AP10
FMC Reference 13
th
Data
N
FMC2_LPC_LA14_P
IO_L18P_T2U_N10_AD2P_64
AH9
FMC Reference 14
th
Data
P
FMC2_LPC_LA14_N
IO_L18N_T2U_N11_AD2N_64
AH8
FMC Reference 14
th
Data
N
FMC2_LPC_LA15_P
IO_L15P_T2L_N4_AD11P_64
AE8
FMC Reference 15
th
Data
P
FMC2_LPC_LA15_N
IO_L15N_T2L_N5_AD11N_64
AF8
FMC Reference 15
th
Data
N
FMC2_LPC_LA16_P
IO_L3P_T0L_N4_AD15P_64
AM11
FMC Reference 16
th
Data
P
FMC2_LPC_LA16_N
IO_L3N_T0L_N5_AD15N_64
AN11
FMC Reference 16
th
Data
N
FMC2_LPC_LA17_CC_P
IO_L12P_T1U_N10_GC_A08_D24_6
5
N24
FMC Reference 17
th
Data
( Clock ) P
FMC2_LPC_LA17_CC_N
IO_L12N_T1U_N11_GC_A09_D25_6
5
M24
FMC Reference 17
th
Data
( Clock ) N
FMC2_LPC_LA18_CC_P
IO_L11P_T1U_N8_GC_A10_D26_65
M25
FMC Reference 18
th
Data
( Clock ) P
