KINTEX UltraScale+ FPGA Board AXKU040 User Manual
37 / 59
www.alinx.com
5
N
FMC2_LPC_LA28_P
IO_L5P_T0U_N8_AD14P_A22_65
J26
FMC Reference 28
th
Data
P
FMC2_LPC_LA28_N
IO_L5N_T0U_N9_AD14N_A23_65
H26
FMC Reference 28
th
Data
N
FMC2_LPC_LA29_P
IO_L3P_T0L_N4_AD15P_A26_65
K26
FMC Reference 29
th
Data
P
FMC2_LPC_LA29_N
IO_L3N_T0L_N5_AD15N_A27_65
K27
FMC Reference 29
th
Data
N
FMC2_LPC_LA30_P
IO_L2P_T0L_N2_FOE_B_65
G25
FMC Reference 30
th
Data
P
FMC2_LPC_LA30_N
IO_L2N_T0L_N3_FWE_FCS2_B_65
G26
FMC Reference 30
th
Data
N
FMC2_LPC_LA31_P
IO_L1P_T0L_N0_DBC_RS0_65
H27
FMC Reference 31
st
Data
P
FMC2_LPC_LA31_N
IO_L1N_T0L_N1_DBC_RS1_65
G27
FMC Reference 31
st
Data
N
FMC2_LPC_LA32_P
IO_L6P_T0U_N10_AD6P_A20_65
J23
FMC Reference 32
nd
Data
P
FMC2_LPC_LA32_N
IO_L6N_T0U_N11_AD6N_A21_65
H24
FMC Reference 32
nd
Data
N
FMC2_LPC_LA33_P
IO_L4P_T0U_N6_DBC_AD7P_A24_
65
J24
FMC Reference 33
rd
Data
P
FMC2_LPC_LA33_N
IO_L4N_T0U_N7_DBC_AD7N_A25_
65
J25
FMC Reference 33
rd
Data
N
FMC2_LPC_SCL
IO_T0U_N12_A28_65
H23
FMC I2C Bus Clock
FMC2_LPC_SDA
IO_T1U_N12_PERSTN1_65
N23
FMC I2C Bus Data
FMC2_DP0_C2M_P
MGTHTXP1_226
W4
Transceiver Data Output
P
FMC2_DP0_C2M_N
MGTHTXN1_226
W3
Transceiver Data Output
N
FMC2_DP0_M2C_P
MGTHRXP1_226
V2
Transceiver Data Input P
FMC2_DP0_M2C_N
MGTHRXN1_226
V1
Transceiver Data Input N
FMC2_GBTCLK0_M2C_P
MGTREFCLK1P_226
T6
Transceiver Reference
Clock P
FMC2_GBTCLK0_M2C_N
MGTREFCLK1N_226
T5
Transceiver Reference
Clock N
