KINTEX UltraScale+ FPGA Board AXKU040 User Manual
38 / 59
www.alinx.com
The 3
rd
FMC HPC Connectors Pin Assignment
Signal Name
FPGA Pin Number
FPGA Pin
Name
Description
FMC_HPC_CLK0_M2C_P
IO_L11P_T1U_N8_GC_67
E25
FMC Reference 1
st
Reference Clock P
FMC_HPC_CLK0_M2C_N
IO_L11N_T1U_N9_GC_67
D25
FMC Reference 1
st
Reference Clock N
FMC_HPC_CLK1_M2C_P
IO_L12P_T1U_N10_GC_66
G10
FMC Reference 2
nd
Reference Clock P
FMC_HPC_CLK1_M2C_N
IO_L12N_T1U_N11_GC_66
F10
FMC Reference 2
nd
Reference Clock N
FMC_HPC_LA00_CC_P
IO_L12P_T1U_N10_GC_67
D24
FMC LA Reference 0
th
Data
( Clock ) P
FMC_HPC_LA00_CC_N
IO_L12N_T1U_N11_GC_67
C24
FMC LA Reference 0
th
Data
( Clock ) N
FMC_HPC_LA01_CC_N
IO_L14P_T2L_N2_GC_67
E22
FMC LA Reference 1
st
Data
( Clock ) P
FMC_HPC_LA01_CC_P
IO_L14N_T2L_N3_GC_67
E23
FMC LA Reference 1
st
Data
( Clock ) N
FMC_HPC_LA02_P
IO_L3P_T0L_N4_AD15P_67
E28
FMC LA Reference 2
nd
Data P
FMC_HPC_LA02_N
IO_L3N_T0L_N5_AD15N_67
D29
FMC LA Reference 2
nd
Data N
FMC_HPC_LA03_P
IO_L5P_T0U_N8_AD14P_67
D28
FMC LA Reference 3
rd
Data
P
FMC_HPC_LA03_N
IO_L5N_T0U_N9_AD14N_67
C28
FMC LA Reference 3
rd
Data
N
FMC_HPC_LA04_P
IO_L2P_T0L_N2_67
C27
FMC LA Reference 4
th
Data
P
FMC_HPC_LA04_N
IO_L2N_T0L_N3_67
B27
FMC LA Reference 4
th
Data
N
FMC_HPC_LA05_P
IO_L8P_T1L_N2_AD5P_67
B25
FMC LA Reference 5
th
Data
P
FMC_HPC_LA05_N
IO_L8N_T1L_N3_AD5N_67
A25
FMC LA Reference 5
th
Data
N
FMC_HPC_LA06_P
IO_L9P_T1L_N4_AD12P_67
C26
FMC LA Reference 6
th
Data
P
