Data ( Clock ) P
FMC_HA00_CC_N
IO_L12N_T1U_N11_GC_68
E17
FMC HA Reference 0
th
Data ( Clock ) N
FMC_HA01_CC_P
IO_L11P_T1U_N8_GC_68
E16
FMC HA Reference 1
st
Data ( Clock ) P
FMC_HA01_CC_N
IO_L11N_T1U_N9_GC_68
D16
FMC HA Reference 1
st
Data ( Clock ) N
FMC_HA02_P
IO_L18P_T2U_N10_AD2P_68
H19
FMC HA Reference 2
nd
Data P
FMC_HA02_N
IO_L18N_T2U_N11_AD2N_68
H18
FMC HA Reference 2
nd
Data N
FMC_HA03_P
IO_L24P_T3U_N10_68
L19
FMC HA Reference 3
rd
Data P
FMC_HA03_N
IO_L24N_T3U_N11_68
L18
FMC HA Reference 3
rd
Data N
FMC_HA04_P
IO_L16P_T2U_N6_QBC_AD3P_68
G19
FMC HA Reference 4
th
Data P
FMC_HA04_N
IO_L16N_T2U_N7_QBC_AD3N_68
F19
FMC HA Reference 4
th
Data N
FMC_HA05_P
IO_L10P_T1U_N6_QBC_AD4P_68
D19
FMC HA Reference 5
th
Data P
FMC_HA05_N
IO_L10N_T1U_N7_QBC_AD4N_68
D18
FMC HA Reference 5
th
Data N
FMC_HA06_P
IO_L23P_T3U_N8_68
K16
FMC HA Reference 6
th
Data P
FMC_HA06_N
IO_L23N_T3U_N9_68
J16
FMC HA Reference 6
th
Data N
FMC_HA07_P
IO_L14P_T2L_N2_GC_68
F18
FMC HA Reference 7
th
Data P
FMC_HA07_N
IO_L14N_T2L_N3_GC_68
F17
FMC HA Reference 7
th
Data N
FMC_HA08_P
IO_L20P_T3L_N2_AD1P_68
K18
FMC HA Reference 8
th
Data P
FMC_HA08_N
IO_L20N_T3L_N3_AD1N_68
K17
FMC HA Reference 8
th
Data N
FMC_HA09_P
IO_L22P_T3U_N6_DBC_AD0P_68
J19
FMC HA Reference 9
th
Data P
