KINTEX UltraScale+ FPGA Board AXKU040 User Manual
43 / 59
www.alinx.com
FMC_HA09_N
IO_L22N_T3U_N7_DBC_AD0N_68
J18
FMC HA Reference 9
th
Data N
FMC_HA10_P
IO_L9P_T1L_N4_AD12P_68
F15
FMC HA Reference 10
th
Data P
FMC_HA10_N
IO_L9N_T1L_N5_AD12N_68
F14
FMC HA Reference 10
th
Data N
FMC_HA11_P
IO_L21P_T3L_N4_AD8P_68
L15
FMC HA Reference 11
th
Data P
FMC_HA11_N
IO_L21N_T3L_N5_AD8N_68
K15
FMC HA Reference 11
th
Data N
FMC_HA12_P
IO_L19P_T3L_N0_DBC_AD9P_68
J15
FMC HA Reference 12
th
Data P
FMC_HA12_N
IO_L19N_T3L_N1_DBC_AD9N_68
J14
FMC HA Reference 12
th
Data N
FMC_HA13_P
IO_L1P_T0L_N0_DBC_68
B14
FMC HA Reference 13
th
Data P
FMC_HA13_N
IO_L1N_T0L_N1_DBC_68
A14
FMC HA Reference 13
th
Data N
FMC_HA14_P
IO_L3P_T0L_N4_AD15P_68
B15
FMC HA Reference 14
th
Data P
FMC_HA14_N
IO_L3N_T0L_N5_AD15N_68
A15
FMC HA Reference 14
th
Data N
FMC_HA15_P
IO_L4P_T0U_N6_DBC_AD7P_68
C19
FMC HA Reference 15
th
Data P
FMC_HA15_N
IO_L4N_T0U_N7_DBC_AD7N_68
B19
FMC HA Reference 15
th
Data N
FMC_HA16_P
IO_L2P_T0L_N2_68
A19
FMC HA Reference 16
th
Data P
FMC_HA16_N
IO_L2N_T0L_N3_68
A18
FMC HA Reference 16
th
Data N
FMC_HA17_CC_P
IO_L13P_T2L_N0_GC_QBC_68
G17
FMC HA Reference 17
th
Data ( Clock ) P
FMC_HA17_CC_N
IO_L13N_T2L_N1_GC_QBC_68
G16
FMC HA Reference 17
th
Data ( Clock ) N
FMC_HA18_P
IO_L17P_T2U_N8_AD10P_68
H17
FMC HA Reference 18
th
Data P
FMC_HA18_N
IO_L17N_T2U_N9_AD10N_68
H16
FMC HA Reference 18
th
