Allen-Bradley 1305 Series User Manual

Block Diagram and Specifications
A-4
Table A.1 Specifications
(continued)
CONTROL OUTPUTS
Programmable
Output 1
Form A Relay Contact: Resistive Rating 115V AC/ 30V DC, 5A; Inductive Rating 115V AC/ 30V DC, 2A
Programmable
Output 2
Open Collector (Sink): 24V DC, 20%, 50 mA maximum
(User supplied source voltage)
Analog Output
(0 to 10V DC)
Load lmpedance  4,000 Ohms, 8 bit resolution
PWM AIgorithm Sine Weighted PWM Output
Switching Device 3-Phase Out-
put
IGBT Intelligent Power Module
V/Hz Ratio Programmable
Carrier Frequency Adjustable in 100Hz Increments from 2 kHz to 8 kHz. Output Current Derating applies above 4 kHz.
DC Boost Adjustable single point or full custom – Start and Run boost available
CONTROL FEATURES
Drive
Bulletin 1305 Drive Rated 200-240 V AC Bulletin 1305 Drives Rated 380-460 V AC
-AA02A -AA03A -AA04A -AA08A -AA12A -BA01A -BA02A -BA03A -BA04A -BA06A -BA09A
AC Dynamic Braking Torque - Estimated - Actual value will depend on motor characteristics
W/0 External Resistor 100% 100% 100% 50% 50% 100% 100% 100% 50% 50% 20%
With External Resistor N/A N/A N/A 150% 100% 150% 150% 150% 150% 100% 100%
Current Limiting Trip Free Operation, Co-ordinated for Drive and Motor Protection
Programmable from 20% to 150% of Drive Rated Current
Overload 200%, Fixed by hardware, based on drive rating
150% for 60 seconds
efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Allen-Bradley 1305 Series Specifications

General

Series	1305
Dimensions	Varies by model
Weight	Varies by model
Frequency Range	50-60 Hz
Control Method	Volts per Hertz
Communication Interface	RS-485
Enclosure Type	IP20
Storage Temperature	-40-70°C
Humidity	5 to 95% non-condensing
