Human Interface Module
3-12
EEPROM MODE (continued)
ACTION
DESCRIPTION
HIM DISPLAY
Drive → HIM
or
or
SEL
❏ 2. To upload a parameter profile from the drive to the HIM, you must have a
Series B HIM.
a. From the EEPROM menu, press the Increment/Decrement keys until
“Drive → HIM” is displayed.
b. Press Enter. Use the Increment/Decrement keys to choose between
profile 1 or profile 2.
c. To give a profile a name, use the SEL key to move the cursor right and
use the Increment/Decrement keys to change the characters. When
done, press Enter to save the name.
d. Press Enter. An informational display will be shown, indicating the
drive type and firmware version.
e. Press Enter to start the upload. The parameter number currently being
uploaded will be displayed on line 1 of the HIM. Line 2 will indicate
total progress. Press ESC to stop the upload.
f. A successful upload will be indicated by “Completed” displayed on line
2 of the HIM. Press Enter. If “Error” is displayed, see Chapter 6.
EEprom
Drive→HIM
Drive→HIM
1
Drive→HIM 45
|||||
Drive→HIM 149
COMPLETE
AC Drive
Version 2.01
Drive→HIM
1 A
