EEPROM MODE (continued)
ACTION
DESCRIPTION
HIM DISPLAY
HIM → Drive
or
or
❏ 3. To download a parameter profile from the HIM to the drive, you must
have a Series B HIM.
Important: The download function will only be available when there is a
valid profile stored in the HIM.
a. From the EEPROM menu, press the Increment/Decrement keys until
“HIM → Drive” is displayed.
b. Press the Enter key. A profile name will be displayed on line 2 of the
HIM. Pressing the Increment/Decrement keys will scroll the display to a
second profile (if available).
c. Once the desired profile name is displayed, press the Enter key. An
informational display will be shown, indicating the version numbers of
the profile and drive.
d. Press Enter to start the download. The parameter number currently
being downloaded will be displayed on line 1 of the HIM. Line 2 will
indicate total progress. Press ESC to stop the download.
e. A successful download will be indicated by “Completed” displayed on
line 2 of the HIM. Press Enter. If “Error” is displayed, see Chapter 6.
EEprom
HIM→Drive
HIM→Drive
1
HIM→Drive 45
|||||
HIM→Drive 149
Completed
AC Drive
2.01 → 2.02
