Allen-Bradley 1305 Series User Manual

Programming
5-10
Setup Group (continued)
[Base Fre
q
uenc
y
]
Parameter # 17 Factory Default 60 Hz
[Base
Frequency]
Parameter Type Read & Write Minimum 40 Hz
This value should be set to the motor nameplate Rated
Frequency.
Units 1 Hz Maximum 400 Hz
[Base Volta
g
e]
Parameter # 18 Factory Default Max. Drive Rated Volts
[Base
Voltage]
Parameter Type Read & Write Minimum 25% of Max. Drive Rated Volts
This value should be set to the motor nameplate Rated
Voltage.
Units 1 Volt Maximum 100% of Max. Drive Rated Volts
[Maximum Volta
g
e]
Parameter # 20 Factory Default Max. Drive Rated Volts
[Maximum
Voltage]
Parameter Type Read & Write Minimum 25% of Max. Drive Rated Voltage
This parameter sets the highest voltage the drive will
output.
Units 1 Volt Maximum 110% of Max. Drive Rated Volts
[Minimum Fre
q
]
Parameter # 16 Factory Default 0 Hz
[Minimum
Freq]
Parameter Type Read & Write Minimum 0 Hz
This parameter sets the lowest frequency the drive will
output.
Important: All analog inputs to the drive (4-20mA, 0-10V,
Remote Pot) are scaled for the range [Minimum Freq] to
[Maximum Freq].
Units 1 Hz Maximum 120 Hz
Important: This parameter can not be
programmed while the drive is running.
efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Allen-Bradley 1305 Series Specifications

General

Series	1305
Dimensions	Varies by model
Weight	Varies by model
Frequency Range	50-60 Hz
Control Method	Volts per Hertz
Communication Interface	RS-485
Enclosure Type	IP20
Storage Temperature	-40-70°C
Humidity	5 to 95% non-condensing
