8 Remote I/O Adapter Module
Publication 1747-IN014C-EN-P - January 2003
Dip Switch Settings
IMPORTANT
The ASB module can be configured as any logical rack number
from 0 to 77 octal. Rack numbers are determined by setting
switches SW1-1 through SW1-6, with ON equivalent to logical 0
and OFF equivalent to logical 1. Then, interpret this 6-bit binary
value as octal with SW1-6 as the least significant bit (LSB). For
example:
SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 Rack
ON OFF ON ON ON OFF 21 (octal)
17 (decimal)
(0) (1) (0) (0) (0) (1)
1
O
N
2456783
SW1
Logical Rack Number Bit 5
(Most Significant Bit)
Logical Rack Number Bit 4
Logical Rack Number Bit 3
Logical Rack Number Bit 2
Logical Rack Number Bit 1
Logical Rack Number Bit 0 (LSB)
Logical Group Number Bit 1 (MSB)
Logical Group Number Bit 0
(Least Significant Bit)
Local Rack Number
ON = 0 OFF = 1
Local Group Number
78Group
ON ON 0 (default)
ON OFF 2
OFF ON 4
OFF OFF 6
