Allen-Bradley 1756 ControlLogix User Manual

ControlNet Overview
Chapter 1
Rockwell Automation Publication CNET-UM001F-EN-P - February 2018 15
SoftLogix virtual chassis, see the SoftLogix5800 System User Manual,
publication 1789-UM002
.
Table 2 - Bridges from a ControlNet Network
Destination
Network
Modules for a 1768 CompactLogix
System
Modules for a 1769
CompactLogix System
Modules for a ControlLogix
Chassis
DeviceNet
• 1768-L43 or 1768-L45 controller
• 1768-CNB(R) module
• 1769-SDN scanner
• 1769-L32C or 1769-L35CR
controller
• 1769-SDN scanner or 1788-
CN2DN module(1)
• 1756-CN2 module
• 1756-CN2R module
• 1756-CNB module
• 1756-CNBR module
• 1756-DNB module
EtherNet/IP
• 1768-L43 or 1768-L45 controller
• 1768-CNB(R) module
• 1768-ENBT module
Not applicable
• 1756-CN2 module
• 1756-CN2R module
• 1756-CNB module
• 1756-CNBR module
• 1756-ENBT module
• 1756-EN2T module
• 1756-EN2TR module
• 1756-EN3TR module
Table 3 - Bridges from an EtherNet/IP Network
Destination
Network
Modules for a 1768
CompactLogix System
Modules for a 1769
CompactLogix System
Modules for a
ControlLogix Chassis
Modules for a 1769
CompactLogix
Packaged Controller
System
ControlNet
• 1768-L43 or 1768-L45
controller
• 1768-ENBT module
• 1768-CNB(R) module
Not applicable
• 1756-CN2 module
• 1756-CN2R module
• 1756-CNB module
• 1756-CNBR module
• 1756-ENBT module
• 1756-EN2T module
• 1756-EN2TR module
• 1756-EN3TR module
Not applicable
DeviceNet
• 1768-L43 or 1768-L45
controller
• 1768-ENBT module
• 1769-SDN scanner
• 1769-L32E or 1769-
L35E controller
• 1769-SDN scanner or
1788-
EN2DN module(1)
• 1756-DNB module
• 1756-ENBT module
• 1756-EN2T module
• 1756-EN2TR module
• 1756-EN3TR module
• 1769-L23E-QB1B
controller
• 1769-L23E-QBFC1B
controller
• 1769-L23-QBFC1B
controller
• 1769-SDN scanner
