Allen-Bradley 1756 ControlLogix - Chapter 7; Communicate with Panelview Terminals; Set up the Hardware

Rockwell Automation Publication CNET-UM001F-EN-P - February 2018 95
Chapter 7
Communicate with PanelView
Terminals
This chapter explains how a controller uses a ControlNet communication
module to communicate with PanelView software products over a
ControlNet network.
Topic Page
Set Up the Hardware on page 95 92 on page 95
Determine Connections to PanelView Terminals on page 96 93 on page 96
Add a PanelView Terminal on page 97 94 on page 97
Organize Controller Data for a PanelView Terminal on page 100 96 on page 100
In this example, the controller in the local chassis shares data with an HMI
application on a ControlNet network. This application could be running any
of these:
• PanelView terminal
• PanelView Plus terminal
• Workstation running RSView 32 software
• Workstation running an RSView Enterprise application, such as
RSView Machine Edition software or RSView Supervisory Edition
software
Figure 14 - Example of Communication with PanelView and RSView
Products
Set Up the
Hardware
