Connect a Computer to the ControlNet Network
28 Rockwell Automation Publication CNET-UM001F-EN-P - February 2018
To configure a ControlNet communication driver, perform this procedure in
RSLinx Classic software.
Important:
If you are using a 1794-U2CN cable to connect to the network, you are not required to configure the driver.
1. From the Communications menu, choose Configure Drivers.
2. From the Available Driver Types pull-down menu, choose a driver
for a ControlNet device.
3. Click Add New.
The Add New RSLinx Driver dialog box appears. The driver name
defaults to AB_xxx.
4. Type the name of the new ControlNet driver.
5. Click OK.
ControlNet
Communication
Driver in RSLinx
Classic Software
