ControlNet Overview
Chapter 1
Rockwell Automation Publication CNET-UM001F-EN-P - February 2018 23
Figure 6 - Example ControlNet Network Star Topology
Item Description
Node
Tap with 1 m (3.28 ft) dropline
Coaxial repeater
